100
HUDSON 8
3.2 Interface
3.2.1 D-Sub Cable
Length : 1.8 M +/- 50 mm
Connector type : D-Sub male with DDC2B pin assignments.
Blue connector thumb-operated jack screws
Pin No. Signal
1 Red
2 Green/ SOG
3 Blue
4 Sense (GND)
5 Cable Detect (GND)
6 Red GND
7 Green GND
8 Blue GND
9 DDC +3.3V or +5V
10 Logic GND
11 Sense (GND)
12 Bi-directional data
13 H/H+V sync
14 V-sync
15 Data clock
3.2.2 DVI Cable
The input signals are applied to the display through DVI-D cable.
Length. : 1.8 M +/- 50 mm
Connector type . : DVI-D male with DDC-2B pin assignments
White connector thumb-operated jackscrews
