Alignments
EN 33SK4.0L CA 8.
8.4 Factory mode Settings
Description of the factory menu Storage address Display string Range (Index value) Default SK4.0L CA
B/W balance
White point R adjustment.
0x00d
DRI R 0-63 32 32
White point G adjustment 0x00e DRI G 0-63 32 32
White point B adjustment 0x00f DRI B 0-63 32 32
Black level off-set R adjustment 0x010 CUT R 0-63 32 32
Black level off-set G adjustment. 0x011 CUT G 0-63 32 32
“BRIGHTNESS” of “White Balance Adjustment page” setting 0x02f BT 0-63 32 32
“CONTRAST” of “White Balance Adjustment page” setting 0x030 CT 0-63 32 32
COOL offset according to “DRI R” value of tv, white point R of “COOL”
0x017 COOL DR 0-63 -2 -2
COOL offset according to “DRI G” value of tv, white point G of “COOL”
0x018 COOL DG 0-63 0 0
COOL offset according to “DRI B” value of tv, white point B of “COOL” 0x019 COOL DB 0-63 10 10
COOL offset according to “CUT R” value of tv, black level off-set R of “COOL”
0x01a COOL CR 0-63 0 0
COOL offset according to “CUT G” value of tv, black level off-set R of “COOL” 0x01b COOL CG 0-63 0 0
WARM offset according to “DRI R” value of tv, white point R of “COOL” 0x01c WARM DR 0-63 10 10
Warm offset according to “DRI G” value of tv, white point G of “COOL”
0x01d WARM DG 0-63 0 0
Warm offset according to “DRI B” value of tv, white point B of “COOL” 0x01e WARM DB 0-63 0 0
Warm offset according to “CUT R” value of tv, black level off-set R of “COOL” 0x01f WARM CR 0-63 0 0
Warm offset according to “CUT G” value of tv, black level off-set R of “COOL”
0x020 WARM CG 0-63 0 0
Direct key “0”
50hz/60hz Frequency 60 Hz
Horizontal center ox008 H PH 0-TV-63-TV 31-TV 35-TV
Vertical slope ox009 V SL 0-63 24 30
Vertical center ox00a V SH 0-63 21 22
Vertical amplitude. ox00b V SI 0-63 33 22
Vertical s-correction. ox00c V SC 0-63 27 19
EW WIDTH 0x04b EW WIDTH 0-63 32 51
EW parabola/width 0x04c EW PARA 0-63 32 45
EW upper/lower corner parabola 0x04d UP CORNER 0-63 32 33
Bottom curve
0x04e LO CORNER 0-63 32 33
Horizontal parallelogram 0x04f H-PARA 0-63 32 35
Horizontal bow 0x050 H-BOW 0-63 32 35
EW trapezium 0x051 EW TRAPE 0-63 32 30
Expand 4:3 mode horizontal WIDTH adjust
0x0ed(bit4)
ZOOM 0-63 44 44
50hz/60hz Frequency 50 Hz
Horizontal center 0x003 H PH 0-TV-63-TV 31-TV 35-TV
Vertical slope 0x004 V SL 0-63 24 31
Vertical center 0x006 V SH 0-63 21 23
Vertical amplitude. 0x005 V SI 0-63 33 22
Vertical s-correction. 0x007 V SC 0-63 27 21
EW WIDTH 0x044 EW WIDTH 0-63 32 49
EW parabola/width 0x045 EW PARA 0-63 32 45
EW upper/lower corner parabola 0x046 UP CORNER 0-63 32 33
Bottom curve
0x047 LO CORNER 0-63 32 33
Horizontal parallelogram 0x048 H-PARA 0-63 32 35
Horizontal bow 0x049 H-BOW 0-63 32 35
EW trapezium 0x04a EW TRAPE 0-63 32 30
Expand 4:3 mode horizontal WIDTH adjust
0x062
ZOOM 0-63 44 44
Horizontal center in AV source.
0x05e H PH +5-AV 32 33
Horizontal center in AV source. 0x05f H PH +5-AV 32 33
Horizontal center in YUV source. 0x05c H PH +0-YUV 32 33
Horizontal center in YUV source. 0x05d H PH +0-YUV 32 33
Direct key “1”
Out of box setting, Smart Picture: Rich, Contrast +: On, NR: Off,
Smart Sound: Theatre, Tuner Mode: Auto, Volume: 30, CC: Off
SHIPMODE OFF ON
RF.AGC adjust 0x002 AGC 0-63 24 23
AGC speed 0x0de (bit5, bit4) AGC SPEED 0-63 1 1
IF choose 0x0dd (bit7, bit6) IF 58.75 Mhz 45.75 Mhz 45.75 Mhz 45.75 Mhz
HRC and IRC of N system for auto search selection 0x0ea (bit4) HRC & IRC OFF ON OFF OFF
ON: PAL M/N ON, OFF: PAL M/N OFF 0x0ea (bit1) MULTI SYSTEM OFF ON ON ON
White apex limit 0x0cb (bit7-bit4) PWL 0-15 0 0
X ray protect 0x0e1 (bit2, bit3) XDT 0-2 1 1
X ray protection detect count 0x073 XDT COUNT 0-255 30 30
NTSC decode matrix 0x0e7(bit2) MUS USA JAP USA USA
PAL, NTSC decode matrix 0x0ed (bit0) MAT OFF ON OFF ON
Bypass of sound bandpass filter 0x0e1 (bit5, bit4) BPB 0-2 1 1
Video dependent coring 0x0de (bit3, bit2) CORING 0-3 3 3
Switch-off in vertical overscan 0x0e7 (bit7) OSO OFF ON ON ON
Direct key “2”
UOC control volume switch 0x0e8 (bit7) UOC VOL SW OFF ON OFF OFF
UOC/PWM modify volume value 0x02e UOC/PWM VOL 0-63 41 40
Volume of 9859 modify value when sound is mono 0x052 MONO GAIN 0-63 48 52
