Alignments
EN 34 SK4.0L CA8.
Volume of 9859 modify value when sound is stereo 0x053 STEREO GAIN 0-63 48 52
Volume of 9859 modify value when sound is SAP 0x054 SAP GAIN 0-63 48 48
Volume of 9859 modify value when system is AV state 0x055 AV GAIN 0-63 48 50
9859 control pin output state
0x0e0 (bit3, bit2)
9859INPUT 0-2 2 1
10% volume point 0x026 VOL 10 0-100 25 45
25% volume point 0x027 VOL 25 0-100 50 55
50% volume point 0x028 VOL 50 0-100 75 75
80% volume point 0x029 VOL 80 0-100 90 85
100% volume point 0x02a VOL 100 0-100 100 100
FM demodulate frequency width 0x0de (bit1, bit0) FMWS 0-2 0 1
AVL function switch
0x0e8 (bit6)
AVL OPT OFF ON OFF OFF
Direct key “3”
AV control logic choose 0x0e1 (bit7, bit6) AV OPT 0-3 1 0
AV choose 0x0cc (bit7-bit4) AV CFG 0-7 3 4
AV2 choose 0x0ea (bit5) 2 AV OFF ON OFF OFF
DVD choose 0x0e9 (bit4) YC/DVD OFF ON OFF OFF
Video output 0x0e7 (bit4)
VIDEO OUT
IF CVBS CVBS CVBS
Pin 5 choose function 0x0cc (bit3-bit0)
PIN 5
NTSC NTSC
Pin 7 choose function 0x0cd (bit7-bit4)
PIN 7
VOL1 VOL1
Pin 8 choose function 0x0cd (bit3-bit0)
PIN 8
MTUE LED
MUTE pin mode 0x0e9 (bit0)
MUTEPIN
MODE
OFF ON OFF
OFF: Pin 7 control volume curve
ON: Pin 4 control volume curve
0x0ee (bit6)
MUTEPIN SEL
OFF
CCD Horizontal width adjust 0x05a
CC HP
0-15 13 13
CCD scan Horizontal row when PAL N system 0x060
CC LINE
0-60 21 21
CCD delay adjustment 0x0d1 (bit3-bit0)
CC DELAY
8-23 20 12
Direct key “4”
OSD up down position 0x02b
VP
0-63 52 52
OSD left right position 0x02c
HP
0-63 54 50
RGB/YUV OSD Horizontal Center 0x05b
YUV OSD HS
0-60 38 38
OSD output contrast 0x0df (bit7, bit6)
OSD L
0-3 0 2
Menu translucence 0x0e9 (bit1)
HALFTONE
OFF ON ON ON
Software version number
SOFTWARE
VERSION
NUMBER
Direct key “5”
Sound mode
BTSC-MODE
MONO STEREO SAP
Stereo noise limit 0x0ce (bit7-bit4)
BTSC-ST
0-15 0 0
SAP noise limit 0x0ce(bit3-bit0)
BTSC-SP
0-15 0 0
Sound input level adjustment 0x040
BTSC-LI
0-15 7 9
Separate 0x041
BTSC-A1
0-31 23 14
Separate 0x042
BTSC-A2
0-31 22 6
Time constant 0x0cf (bit7-bit4)
BTSC-TC
0-7 4 3
Stereo level switch 0x0e8 (bit3)
BTSC-STS
OFF ON OFF ON
Stereo adjustment on/off 0x0e8 (bit2)
BTSC-ADJ
BUSY START START START
MTS detect time delay 0x001
MTS DETECT
0-255 50 50
STEREO and SAP detect count 0x072
MTS FILTER
0-255 20 20
MONO detect count 0x074
MTS FILTER2
0-255 20 3
Direct key “6”
POWER ON MODE 0x0dd (bit3, bit2)
POW
0-2 2 2
POWER ON time delay 0x0cb (bit3-bit0)
POWER ON TIM
2-17 12 8
Black current stabilization 0x0e8 (bit0)
AKB
OFF ON ON ON
Black current loop detect 0x0e9 (bit7)
NBL
OFF ON ON ON
WATCH DOG 0x0eb (bit7)
WATCHDOG
OFF ON OFF OFF
ON: Philips RC
OFF: Skyworth RC
0x0eb (bit6)
PHILIPS RC
OFF ON ON ON
VCHIP FUNCTION SWITCH 0x0ea (bit7)
VCHIP
OFF ON OFF OFF
GAME FUNCTION SWITCH 0x0eb (bit5)
GAME
OFF ON OFF OFF
CALENDER FUNCTION SWITCH 0x0eb (bit4)
CALENDER
OFF ON OFF OFF
4:3 expand function choose 0x0ec (bit6)
ZOOM OPT
OFF ON ON OFF
ON: Blue Screen
OFF: Black Screen
0x0e9 (bit6)
BLUE BLACK
OFF ON ON ON
EW WIDTH offset according to “EW WIDTH” value when TV is no signal 0x06d
BB WIDTH
53-10 +0 0
Video mute during change to program 0x0e1 (bit1, bit0)
BLACK BACK
0-2 0 0
RGB BLANKING 0x0ee (bit7)
RGB BLANKING
OFF ON ON ON
Direct key “7”
Sub contrast 0x057
SUB BRI
0-63 0 4
Sub brightness 0x059
SUB CON
0-63 0 3
Sub color 0x023
SUB COL
0-63 30 30
Sub Sharpness 0x024
SUB SHA
0-63 32 32
TV Sub tint 0x025
SUB TIN
0-31 16 16
AV Sub tint 0x075
SUB TIN-AV
0-31 16 16
PAL Luminance delay 0x0c9 (bit3-bit0)
YDL PAL
0-15 2 2
NTSC Luminance delay 0x0c9 (bit7-bit4)
YDL NTSC
0-15 2 2
Description of the factory menu Storage address Display string Range (Index value) Default SK4.0L CA
