Philips 21PT9457 - Page 35

Alignments
EN 35SK4.0L CA 8.
AV Luminance delay 0x0ca(bit7-bit4)
YDL AV
0-15 4 2
Maximum brightness 0x056
MAX BRI
0-63 63 63
Middle brightness 0x021
MID BRI
0-63 18 18
Maximum contrast 0x058
MAX CON
0-63 63 63
Middle contrast 0x022
MID CON
0-63 15 15
Line-level of brightness 0x02d
SC.BRI
0-63 8 8
Direct key “8”
YUV offset according to “DRI R” value of TV, white point R of YUV. 0x012
YUV DR
(-32) - (+31) +0 +0
YUV offset according to “DRI G” value of TV, white point G of YUV 0x013
YUV DG
(-32) - (+31) +0 +0
YUV offset according to “DRI B” value of TV, white point B of YUV 0x014
YUV DB
(-32) - (+31) +0 +0
YUV offset according to “CUT R” value of TV, black level offset R of YUV 0x015
YUV CR
(-32) - (+31) +0 +0
YUV offset according to “CUT G” value of TV, black level offset G of YUV 0x016
YUV CG
(-32) - (+31) +0 +0
English OSD switch 0x0eb (bit3)
ENGLISH
OFF ON ON ON
Spanish OSD switch 0x0eb (bit2)
SPANISH
OFF ON ON ON
French OSD switch 0x0eb (bit1)
FRANCE
OFF ON OFF OFF
Portuguese OSD switch 0x0eb (bit0)
PORTUGUESE
OFF ON ON ON
External Y (Luminance) input gain during YPRPB.
OFF: gain 0 dB reduced, ON: gain 3 dB reduced
0x0ee (bit4)
YGN
OFF ON OFF ON
Cathode drive level 0x0ca (bit3-bit0)
CATHE
33
EHT tracking mode 0x0ea (bit6)
HCO
ON ON
Black current measuring lines in overscan 0x0e9 (bit2)
OSVE
OFF OFF
Manual INIT E2PROM
INITEEP
Key “Smart sound”
BASS set value in Voice state 0x064
BASS
30 30
TREBLE set value in Voice state 0x065
TREBLE
50 50
SURROUND set value in Voice state 0x066
SURROUND
OFF OFF
BASS set value in Music state 0x067
BASS
55 55
TREBLE set value in Music state 0x068
TREBLE
60 60
SURROUND set value in Music state 0x069
SURROUND
OFF OFF
BASS set value in Theatre state 0x06a
BASS
80 80
TREBLE set value in Theatre state 0x06b
TREBLE
70 70
SURROUND set value in Theatre state 0x06c
SURROUND
ON ON
Key “Smart image”
Bright set value in Soft state 0x036
BRIGHT
55 55
Contrast set value in Soft state 0x037
CONTRAST
50 50
Color set value in Soft state 0x038
COLOR
45 45
Sharpness set value in Soft state 0x039
SHARP
45 45
Sharpness set value in Soft state of YUV 0x070
YUV SHARP
50 50
COLOR TEMP set value in Soft state 0x03a
COLOR TEMP
WARM WARM
Bright set value in Rich state 0x03b
BRIGHT
70 70
Contrast set value in Rich state 0x03c
CONTRAST
85 85
Color set value in Rich state 0x03d
COLOR
70 70
Sharpness set value in Rich state 0x03e
SHARP
70 70
Sharpness set value in Rich state of YUV 0x071
YUV SHARP
80 80
COLOR TEMP set value in Rich state 0x03f
COLOR TEMP
COOL COOL
Bright set value in Natural state 0x031
BRIGHT
50 50
Contrast set value in Natural state 0x032
CONTRAST
75 75
Color set value in Natural state 0x033
COLOR
50 50
Sharpness set value in Natural state 0x034
SHARP
50 50
Sharpness set value in Natural state of YUV 0x06f
YUV SHARP
50 50
COLOR TEMP set value in Natural state 0x035
COLOR TEMP
NORMAL NORMAL
Description of the factory menu Storage address Display string Range (Index value) Default SK4.0L CA
