Mechnical instructions (ME)
1. Press the release button, Then take
off the base.
2. Remove 4pcs screw from the join of
hinge & back cover, Than take off the
hinge
3.Take off the back cover.
4. Disconnect the cable of function key.
5.Disconnect the lamp cable form power
board.
6.Take off the 4 screws which fixed the
chassis and panel.. The other 2 screws
locate on the other side.
Release
button
1
2
3
4
1
2
To Next Page
