Philips 231E1HSB/00 - DDC Data

231E1
LCD
18
DDC Data
THE DISPLAY DATA CHANNEL (DDC_2B) CONTENT INCLUDING:
Analog mode:
0 1 2 3 4 5 6 7 8 9 A B C D E F
0
00 FF FF FF FF FF FF 00 41 0C 2B C0 01 01 01 01
1
23 12 01 03 0E 33 1D 78 EE C9 A5 A4 56 4B 9D 25
2
12 50 54 B7 4B 80 81 80 95 00 A9 40 B3 00 01 01
3
01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
4
45 00 FE 1F 11 00 00 1A 00 00 00 FD 00 38 4C 1E
5
53 14 00 0A 20 20 20 20 20 20 00 00 00 FC 00 50
6
68 69 6C 69 70 73 20 32 33 30 45 0A 00 00 00 FF
7
00 30 30 30 30 30 30 30 30 30 30 30 30 30 00 D3
Byte(Hex) Field Name and Comments Description EDID
00~07h Head Information 00,FF,FF,FF,FF,FF,FF,00
08~09h ID Manufacturer Name PHL 41,0C
0A~0Bh Product ID Code C02B 2B,C0
0C~0Fh Last 5 Digits of Serial Number Not used 01,01,01,01
10h Week of Manufacture 35 23
11h Year of Manufacture 2008 12
12h EDID Version Number 1 01
13h EDID Revision Number 3 03
Analog Signal Level
0.700, 0.300 (1.000Vp-p)
No Blank -to-black Setup
Separate Syncs. Supported
Composite Sync. Supported
Sync. on Green Supported
14h Video Input Definition
No Serration Required
0E
15h Max Horizontal Image Size 51 cm 33
16h Max Vertical Image Size 29 cm 1D
17h Display Gamma 2.2 78
Standby
Suspend
Active Off/Very Low Power
RGB Color Display
sRGB Color Space
Preferred Timing Mode
18h Power Management and
Supported Feature(s)
No Default GTF Supported
EE
R (x, y) 0.644, 0.336
G (x, y) 0.295, 0.614
B (x, y) 0.146, 0.072
19~22h Chroma Info
W (x, y) 0.313, 0.329
C9,A5,A4,56,4B,9D,25,12,
50,54
720 x 400 @ 70Hz
720 x 400 @ 88Hz (N/A)
23h
Established Timing I
640 x 480 @ 60Hz
B7
