Philips 231E1HSB/00 - Description

231E1
LCD
20
For DVI:
0 1 2 3 4 5 6 7 8 9 A B C D E F
0
00 FF FF FF FF FF FF 00 41 0C 2B C0 01 01 01 01
1
23 12 01 03 80 33 1D 78 EE C9 A5 A4 56 4B 9D 25
2
12 50 54 B7 4B 80 81 80 95 00 A9 40 B3 00 01 01
3
01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
4
45 00 FE 1F 11 00 00 1A 00 00 00 FD 00 38 4C 1E
5
53 11 00 0A 20 20 20 20 20 20 00 00 00 FC 00 50
6
68 69 6C 69 70 73 20 32 33 30 45 0A 00 00 00 FF
7
00 30 30 30 30 30 30 30 30 30 30 30 30 30 00 64
Byte(Hex) Field Name and Comments Description EDID
00~07h Head Information 00,FF,FF,FF,FF,FF,FF,00
08~09h ID Manufacturer Name PHL 41,0C
0A~0Bh Product ID Code C02B 2B,C0
0C~0Fh Last 5 Digits of Serial Number Not used 01,01,01,01
10h Week of Manufacture 35 23
11h Year of Manufacture 2008 12
12h EDID Version Number 1 01
13h EDID Revision Number 3 03
14h Video Input Definition
Digital Signal Level
80
15h Max Horizontal Image Size 51 cm 33
16h Max Vertical Image Size 29 cm 1D
17h Display Gamma 2.2 78
Standby
Suspend
Active Off/Very Low Power
RGB Color Display
sRGB Color Space
Preferred Timing Mode
18h Power Management and
Supported Feature(s)
No Default GTF Supported
EE
R (x, y) 0.644, 0.336
G (x, y) 0.295, 0.614
B (x, y) 0.146, 0.072
19~22h Chroma Info
W (x, y) 0.313, 0.329
C9,A5,A4,56,4B,9D,25,12,
50,54
720 x 400 @ 70Hz
720 x 400 @ 88Hz (N/A)
640 x 480 @ 60Hz
640 x 480 @ 67Hz
640 x 480 @ 72Hz(N/A)
640 x 480 @ 75Hz
800 x 600 @ 56Hz
23h
Established Timing I
800 x 600 @ 60Hz
B7
800 x 600 @ 72Hz(N/A)
800 x 600 @ 75Hz
832 x 624 @ 75Hz(N/A)
1024 x 768 @ 87Hz(I) (N/A)
1024 x 768 @ 60Hz
1024 x 768 @ 70Hz(N/A)
24h
Established Timing II
1024 x 768 @ 75Hz
4B
