Philips 231E1HSB/00 - Page 34

231E1
LCD
34
231E1SB/93
PN:8231V161W060RR(INL)
Part Name PHILIPS P/N PCM CODE Description Q'ty Location Remark
Electronic LCD panel 631102230111H PANEL MT230DW01-V0-G1(INL) 1 5 INL PANEL
LCD panel 631102230112H PANEL MT230DW01-V0-G2(INL) 0 5
LCD panel 631102230113H PANEL MT230DW01-V0-G3(INL) 0 5
Components: MB-LCD cable 430303002300R HRN LVDS FFC 30P 196M 1 34
MB-EB 430301000270R
HRN ASSY 2x5P to 4P、8P
1 35
IC 412000224482R IC AT24C16BN-SH-T 1 U106, ATMEL,
IC 412000435481R IC AT24C02BN-SH-T 1 U103, ATMEL,
IC 412000700950R IC NT68667UFG QFP128 1 U105, NOVATEK,
TRANSISTOR 426000091220R XFMR SW ERL28 TP4 550uH SPW-122 1 T850, FOXCONN,FRONTIER,LISHIN,MEIKAI,
TRANSISTOR 426000091060R XFMR SW DIP EEL19 P4 878mH SPW-106 1 T1,T2, DARFON,FOXCONN,HUALON,LISHIN,
Mechanical STAND 714011207001R STAND ASSEMBLY 1 15
Componenents : OSD BUTTON 750020202100R OSD BUTTON SLIVER PRINTING 1 9
HOLDER KEYPAD 501060201200R HOLDER KEYPAD 1 8
Power board 792451400A00R POWER BOARD PCBA 1 12
Interface board 793101300600R INTERFACE BOARD PCBA 1 7
Switch board 792451500000R SWITCH BOARD PCBA 1 10
PCBA:
Led board 792450500000R LED BOARD PCBA 1 4
Front bezel 714030031000R FRONT BEZELassembly 1 1
Cabinets:
Back cover 714050023303R BACK-COVER assembly 1 14
VGA CABLE 453010100320R CABLE D-SUB BLACK/BLUE 1 22
POWER CORD 453070800170R PWR CORD 16A/250V BLK 6FT 1 20
DVI CABLE 453030300400R CABLE DVI-D BLACK 1 21
CD 506070127300R USER'S(CD) manual 1 30
Accessories:
GUIDE QUICK 506280116500R GUIDE QUICK SETUP 1 31
Packing EpE bag 506120004701R PE BAG 1 27
Material: EpE bag 506120304900R PE BAG 1 28
Carton 506020034500R CARTON 1 29
Cusion 506040014700R CUSHION,EPS-TOP 1 25
Cusion 506040014701R CUSHION ,EPS-BOTTOM 1 26
