Technical Data
2. Pin Assignment
2.1 PC analog video input with D - sub connector.
Connector type of analog signal cable :
D - Sub male with DDC2B pin assignment.
Blue connector with thumb-operated jackscrews.
Pin assignment :
.
2.2 PC digital video input with DVI-D connector
Automatic
Power
Saving
If
you
have
VESA
/
DPMS
compliance
display
card
or
software
installed
in
your
PC,
the
monitor
can
automatically
reduce
power
consumption
when
power
saving
function
active.
And
if
an
input
from
keyboard,
mouse
or
other
devices
is
detected,
the
monitor
will
automatically
wake
up.
The
following
table
shows
the
power
consumption
and
signaling
of
this
automatic
power
saving
feature:
Status Power
LED
Remark
Power On ≤ 58W
Blue
Power Saving
≤0.5W
Blinking Blue
Power Off ≤ 0.5W
Off
The volume should
be minimum when
test power saving.
This
monitor
must
comply
with
the
Microsoft
On
Now
specification,
with
two
power
management
states,
as
defined
by
the
VESA
DPMS
document.
And
must
appropriately
display
the
DPMS
states.
Also
comply
with
Environmental
Protection
Agency
(EPA)
Energy
Star
and
TCO03
power
management
standard
strictly
ENERGY
STAR
is
a
U.S.
Registered
mark.
AS
AN
ENERGY
STAR
PARTNER,
PHILIPS
HAS
DETERMINED
THAT
THIS
PRODUCT
MEETS
THE
ENERGY
STAR
GUIDELINES
OF
ENERGY
EFFICIENCY.
Factory preset mode: (FW)
This monitor has 15 factory-preset modes as indicated in the
following table
1 Red 6 Red GND
11 GND
2 Green/SOG
7
Green
GND
12
Bi-directional
data
3 Blue 8 Blue GND
13 H sync
4 GND 9 +5V 14 V sync
5 CableDetect
10 Open 15 Data clock
Item
H.Freq.
(KHz)
Mode Resolution
V.Freq.
(Hz)
BW(MHz)
1
31.469
IBM VGA 3H
720x400
70.087
28.3
2
31.469
IBM VGA 12H
640x480
59.94
25.175
3
35 MACINTOSH
640x480
67 30.24
4
37.5 VESA 640x480
75 31.5
5
35.156
VESA 800x600
56.25
36
6
37.879
VESA 800x600
60.317
40
7
46.875
VESA
800x600
75 49.5
8
48.363
VESA 1024x768
60.004
65
9
60.023
VESA 1024x768
75.029
78.75
10
63.981
VESA
1280x1024
60.02
108
11
79.976
VESA 1280x1024
75.025
135
12
66.587
CVT 2.3MA-R
1920x1080
60 138.5
13
67.5 CEA 861 1920x1080
60 148.5
14
65.29
CVT1.76MW
1680X1050
60 146.25
15
70.635
CVT1.76MW-R
1680X1050
60 119
Pin
Symbol Pin
Symbol Pin
Symbol
1 T.M.D.S. data2-
9 T.M.D.S. data1-
17 T.M.D.S. data0-
2 T.M.D.S. data2+
10 T.M.D.S. data1+
18 T.M.D.S. data0+
3
T.M.D.S. data2
shield
11
T.M.D.S. data1
shield
19
T.M.D.S. data0
shield
4 No Connect 12 No Connect 20 No Connect
5 No Connect 13 No Connect 21 No Connect
6 DDC clock 14 +5V Power 22
T.M.D.S clock
shield
7 DDC data 15
23 T.M.D.S. clock+
8 No Connect 16 Hot plug detect
24 T.M.D.S. clock-
