241B4LPY LCD
ʳ
General Product Specification
ʳ
3 Product ID, "xxxx" 4 codes MSB(byte 12): 08
ʳʳ LSB (byte 11): B3
4 maximum resolution 1920x1080
5 Horizontal Frequency Range 30~83 KHz
6 Vertical Frequency Range 56~76Hz
7 Monitor Name (13 characters max.) 241BLPY
Panel
Suppliers to offer panel specifications.
Panel incoming specification: Follow Philips’ specification.
AUO M240HW01 VD
Type NR. : AUO M240HW01 VD
Resolution : 1920 x 1080 (FHD)
Outline dimensions : 556.0(H) x 323.2(V) x 11.5(D) mm
Pixel Pitch ( mm ) : 0.27675mm x 0.27675mm
Color pixel arrangement : 1920 horiz. by 1080 vert. Pixels. RGB stripe arrangement
Display surface treatment : Hard coating (3H), anti-glare treatment of the front polarizer.
Color depth : 16.7 M colors 8-bit with A-FRC, 16.7M colors
Backlight : WLED
Active area (W x H) : Vertical 531.36mm x Horizontal 298.89 mm
View angle (CR>10) : >=170/160 for H/V
Contrast ratio : 1000:1(Typ.)
White luminance : 250 nit(Typ.)
Color gamut : 72% (Typ.)
2.2 Scanning frequencies
Hor. : 30 – 83 KHz
Ver. : 50 - 76 Hz
Video dot rate:
241S4L / 241S4LA / 241S4LC / 241B4LP :
Analog : Support RGB WUXGA 1920x1200@60, 2048x1152@60hz input for NT68668UMFG
205Mhz HPLL With 64 steps phase Adjust for RGB Channel in NT68777UMFG
Digital : Integrated Single Link TMDS Receiver up To 225MHz deep color mode
241S4LY / 241B4LPY :
Analog: RTD 2486D Integrated 8-bit triple-channel 210MHz ADC/PLL (over 2048x1152@60hz
input), High resolution true 64 phase ADC PLL, YPbPr support up to HDTV 1080p
resolution.
Digital: DVI Single link on-chip TMDS receiver up to 165MHz; DP Support 4 lanes digital input,
each lanes speed up to 1.62Gbps Hz and 2.7Gbps Hz
Power input: 90-264 V AC, 50/60 r 3 Hz
