3.3 OSD/Keypad functions
ITEM
1 OSD/keypad definition
ˠˇʳˢ˦˗ʳ˕ʳ
˷˸˹˼˼˼ʳ˲ʳ˅˃˄˄˃ˉ˃
ˆ
Reset -
No : Exit
Yes : Auto adjustment for
displaying timing mode and
recall factory preset
2 OSD Translation
ˢ˦˗˲˦˼˺˲ˠˇ˲˅˃˄
˄˃ˈ˅˃
8 LANGUAGES, w/o Turkish.
3 Power On logo
ˣ˻˼˿˼˲˟˺˲˄ˌ˅˃
˄˃ˋ˃ˁ˵
Power On Logo:
Power On Show up Philips logo 3
seconds
Æ Change to input signal.
This picture is reference only.
The official drawing will send
out by PM.
3.4 Horizontal scanning
Sync polarity : Positive or Negative
Scanning frequency : 30 – 83 K Hz
3.5 Vertical scanning
Sync polarity : Positive or Negative
Scanning frequency : 56 - 76 Hz
3.6 Power input connection
Power cord length : please refer to M4 cable bundle summary file
Power cord type : 3 leads power cord with protective earth plug.
3.7 Power management
The monitor must comply with the Microsoft On Now specification, and meet EPA requirements.
Mode HSYNC VSYNC Video Pwr-cons. Indication Rec. time
Power-On On On Active
241S4L, 241S4LC, 241S4LY <32W(max.)
241S4LA, 241B4LP, 241B4LPY <45W(max.)
EPA5.0 < 33.97W
White LED --
