241B4LPY LCD
ʳ
General Product Specification
ʳ
2). DVI-D Digital (optional for 241S4L / 241S4LA / 241S4LC / 241B4LP )
Input signal: Single TMDS link (Three channels: RX0-/+, RX1-/+, RX2-/+)
3). Display port (241S4LY / 241B4LPY)
3.1 Interface
3.1.1 D-Sub Cable
Length : Please refer to M4 cable bundle summary file
Fix with monitor when packing, with transplant pin protective cover.
Connector type : D-Sub male with DDC2B pin assignments.
Blue connector thumb-operated jack screws
Pin assignments:
PIN No. SIGNAL
1Red
2 Green/ SOG
3 Blue
4 Sense (GND)
5 Cable Detect (GND)
6 Red GND
7 Green GND
8 Blue GND
9 DDC +3.3V or +5V
10 Logic GND
11 Sense (GND)
12 Bi-directional data
13 H/H+V sync
14 V-sync
15 Data clock
3.1.2 DVI Cable
The input signals are applied to the display through DVI-D cable.
Length : Please refer to
cable bundle summary file
Connector type : DVI-D male with DDC-2B pin assignments
White connector thumb-operated jackscrews with transplant pin protective cover.
Pin Assignment:
Pin No. Description
1 T.M.D.S. data2-
2 T.M.D.S. data2+
3 T.M.D.S. data2 shield
4 No Connect
