Revision List
EN 2 TCM3.1A LA1.
2010-Jun-25
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
• Chapter 2: “Described Model Numbers” overview updated
and connector overview adapted.
• Chapter 5: Updated SDM initial settings. “Op. Hours”
description adapted. Updated Layer 1 code overview.
• Chapter 6: Updated White Tone default settings.
2. Technical Specifications and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connection Overview
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Here is product information available, as well as getting started,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model numbers
2.2 Directions for Use
Click on the hyperlinks in table above.
2.3 Connection Overview
Figure 2-1 Rear and side I/O connections
CTN Styling Published in SM
32HFL3331/93
Click
3122 785 18521
32HFL3331/97
3122 785 18521
32PFL3409/93
3122 785 18520
32PFL3409/98
3122 785 18520
32PFL3609S/98
3122 785 18521
42HFL3381/93
3122 785 18521
42PFL3609/93
3122 785 18520
42PFL3609/98
3122 785 18520
42PFL3609S/98
3122 785 18521
47PFL3609/93
3122 785 18520
47PFL3609/98
3122 785 18520
47PFL3609S/98
3122 785 18521
