Philips 55BDL4050D - Input;Output Terminals Identification

55BDL4050D
7
2.2. Input/Output Terminals
11
12
13
16
18
17
19
15
20
21 43 6
5
8
7
10
9
14
1
AC SWITCH
Switchthemainpoweron/off.
2
AC IN
ACpowerinputfromthewalloutlet.
3
HDMI1 IN /
4
HDMI2 IN
HDMIvideo/audioinput.
5
IR IN /
6
IR OUT
IRsignalinput/outputfortheloop-throughfunction.
7
RJ-45
LANcontrolfunctionfortheuseofremotecontrolsignalfrom
controlcenter.
8
RS232 IN /
9
RS232 OUT
RS232networkinput/outputfortheloop-throughfunction.
10
Audio OUT
AudiooutputtoexternalAVdevice.
11
USB PORT B
TouchconnectortoPC.
12
USB PORT A
USB
5V/2A
13
PC LINE IN
AudioinputforVGAsource(3.5mmstereophone).
14
DVI IN
DVI-Ivideoinput.
15
DVI OUT
DVIorVGAvideooutput.
16
DisplayPort IN /
17
DisplayPort OUT
DisplayPortvideoinput/output.
18
MICRO USB
ConnectyourUSBstoragedevice.
19
MICRO SD CARD
ConnectyourMICROSDCARD.
20
SECURITY LOCK
Usedforsecurityandtheftprevention.
