Philips 55PFL4909 - Mechanical Parts; Parts List

2014/05/07 13-1 A4DR2CA.fm
TYPE A
PARTS LIST [55PFL4909/F7 (Serial No.: DS1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
LCD PANEL ASSEMBLY#
Ref. No. Description Part No.
A3-1 REAR CABINET L A4DR2UH 2EMM00327A
A3-2 REAR CABINET R A4GR0UH 2EMM00261A
A5 DECORATION PLATE A4D1BUH 2EMH00289
A7 FUNCTION KNOB A4GF1UT 2EMM00237
A8 KNOB FRAME A4DFAUT 2EMM00325
A9 LED LENS A4DFAUT 2EMM00301
A13 JACK HOLDER A37U0UH 1EM334736
A15# RATING LABEL A4DR2UH ----------
A16 LOGO LABEL A4DFAUT ----------
A17 ENERGY GUIDE LABEL A4DR2UH ----------
A20 LEADING EDGE COVER A4D1BUH 2EMM00294
A26 SPEAKER HOLDER A4GU0UT 2EMM00248
AC601# AC CORD W/O A GND WIRE UL/CSA/1775/NO/
BLACK
WAC172LTE010
B7 T-CON HOLDER A4D1BUH 2EMS00151
B10 STAND BRACKET A4GR0UH 2EMS00157
B12 SENSOR SHIELD A4GF1UT 2EMS00133
B17 WALL MOUNT BRACKET A4GU0UT 2EMS00136
B18 WALL MOUNT COVER A4GU0UT 2EMM00263
B23 WIRE LABEL A3AF0UT ----------
B31 BLIND LABEL A4D1BUH ----------
CL3013 FFC WIRE ASSEMBLY 51PIN W/SHIELD
51PIN/592MM
WX1A4DR2P401
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/
669MM
WX1A4GR0S201
CL3601 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/
400MM
WX1A4DR2S101
CL3801 WIRE ASSEMBLY 4PIN 4PIN/765MM&185MM WX1A4GR0C401
CL4001 WIRE ASSEMBLY 2PIN 2PIN/585MM WX1A4GR0C301
L10 SCREW F-PAN BLACK_NI +P-TITE M3X12.0
3X12 WASHER HEAD+BLK
GCHP3120
L23 SCREW BIND 3CHROM +S-TITE M3X6.0 M3X6
BIND HEAD+
GBJS3060
L28 SCREW F-PAN BLACK_NI +S-TITE M3X8.0 3X8
WASHER HEAD+BLAC
GCHS3080
L42 SEMS-SW PAN BLACK_NI + M4X12.0 M4X12 +
BLAK
FPH34120
SBA1 STAND BASE ASSEMBLY A4D17UH 2EMA00059
SNA1 STAND NECK A4D17UH 2EMZ00151
SP3801 SPEAKER MAGNETIC 8OHM/10W S0411F26 DS08110XQ006
SP3802 SPEAKER MAGNETIC 8OHM/10W S0411F26 DS08110XQ006
SSK1 STAND SCREW KIT A3AU0UH(SEMS-SW PAN
BLACK_NI + M4X12.0)
1ESA34506
PAC KI NG
S1 CARTON (TOP) A4DR2UH 2EMC00288
S2 CARTON (BOTTOM) A4GR0UH 2EMC00287
S3 STYROFOAM TOP A4GR0UH 2EMC00284
S4 STYROFOAM BOTTOM A4GR0UH 2EMC00285A
S6 SET BAG A17RHUH 1EM334731
S7 SERIAL NO. LABEL A4GF1UT ----------
S10 PROTECTION CARTON A4GR0UH 2EMC00331
S16 PACKING JOINT A4GR0UH 2EMC00345
ACCESSORIES
X1 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579
X2# OWNERS MANUAL A4D1BUH 2EMN00154
X3 REMOTE CONTROL UNIT YKF340-003 URMT41JHG003
X4 BATTERY DRY R03(SIZE AAA ) XB00M0RKT001
X6 QUICK START GUIDE A4D17UH 2EMN00176
X22 WARNING MESSAGE FLIER A3AU2UH 2EMN00059A
Ref. No. Description Part No.
LCD1# LCD PANEL ASSEMBLY U4DR0P0
LCD MODULE ----------
Ref. No. Description Part No.
