Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
55PFL4909/F7 (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A4GRAMMA-003
CN3701 Not used
IC3006 IC 32M-BIT SERIAL FLASH MEMORY
W25Q32FVSSIG
NSCA0R0ZM018
IC3009 IC RESET IC-PST8429UR QSCA0T0MM075
IC3019 IC USB HIGH-SIDE SW AP2151WG-7/SOT25/
5PI
NSCA0TDES015
IC3101 IC MSD8220LB1-S1 MSD8220LB1-S1 EPLQFP NSAA0RMST002
IC3102 Not used
IC3103 Not used
IC3201 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3601 IC REGULATOR BD00IA5WEFJ-E2 QSCA0T0RM233
IC3602 REGULATOR AP1117EG-13 NSCA0TDES012
IC3603 IC REGULATOR BD00IA5WEFJ-E2 QSCA0T0RM233
IC3604 IC DC-DC CONVERTER MP2314GJ-Z TSOT23-
8
NSCA0T09M025
IC3605 IC DC-DC CONVERTER MP2314GJ-Z TSOT23-
8
NSCA0T09M025
IC3607 Not used
IC3701 Not used
IC3801 IC D-CLASS AUDIO POWER AMPLIFI
TPA3110D2PWPR
NSCA0T0TY073
IC3803 Not used
IC3851 IC STEREO HEADPHONE AMPLIFIER
TS488IQT DFN8 8PIN
NSCA0T0SS070
IC3901 Not used
TU3001 Not used
TU3901 TUNER UNIT U9004UH U9004UH
IC3401 Not used
IC3402 Not used
POEWER SUPPLY CBA A4GR0MPW-001
C728 Not used
C729 Not used
D715 Not used
D716 Not used
Q703 Not used
Q705 Not used
R656 RES CHIP 1608 1/10W J 100k  RRXA104HH013
R748 Not used
R749 Not used
R750 Not used
R751 Not used
R752 Not used
R753 Not used
R754 Not used
R755 Not used
R756 Not used
Ref. No. Description Part No.
