User Manual BDL4771V
RETURN TO THE CONTENTS
3.5. EXTERNAL AUDIO CONNECTION
3.5.1. CONNECTING EXTERNAL SPEAKERS
1. Connect the speaker wires to the external speaker (SPEAKERS) output of the display.
2. Turn on the unit.
Note: Make sure your display is turned off before connecting the speaker wires.
3.5.2. CONNECTING EXTERNAL AUDIO DEVICE
Connect the red (R) and white (L) audio jacks of the external audio device to the AUDIO OUT R/L jacks of the display.
