Specifications 51
General
CRT: 9-inch in line gun
Television system: NTSC-M
Video Heads: Two heads
Tape width: 1/2 inch (12.65 mm)
Tape speed
SP: 33.35 mm/sec.
LP: 16.67 mm/sec.
SLP: 11.12 mm/sec.
Operating Temperature: 41˚F (5˚C) to 104˚F (40˚C)
Relative Humidity: 10% to 75%
Power requirement: AC 120V/DC 13.2V, 60Hz
Power consumption: 55W (AC), 60W (DC)
Sound output: 0.8W
Dimensions:
13" (H) x 12-1/8" (W) x 12-15/16" (D)
330mm x 308mm x 329mm
12-7/8" (H) x 12-1/6" (W) x 12-7/8" (D)
326mm x 306mm x 326mm
Weight: 18.8 lbs (8.5 kg)
Tuner Broadcast Channels
VHF 2-13, UHF 14-69
Cable TV Channels
1-125
Terminals
Antenna In: VHF/UHF 75 ohms unbalanced
Video In: RCA connector
Audio In: RCA connector
Earphone: 3.5 mm CES
Electrical Specifications
Video input level: 0.5~2.0Vp-p
Audio input level: -10dBv
Video S/N ratio
SP: More than 42dBµ
Audio S/N ratio
SP: More than 38dB
Designs and specifications are subject to change without notice and without our
legal obligation.
(CCC090)
(CCC092)
