1 ABOUT THIS MANUAL
This "Instructions For Use" manual
provides all the information required to
install and operate the CCS 800
Discussion System.
CONVENTIONS
Warnings: Warnings draw
attention to instructions that must
be followed to prevent personal
injury.
Caution: Cautions draw attention
to instructions that must be
followed to prevent damage to
the equipment.
Notes: Notes draw attention to
special instruction tips or other
useful information.
2 INTRODUCTION
The Philips CCS 800 Discussion System
is a discussion system for use in meeting
and conference venues with a limited
number of participants.
A CCS 800 Discussion System consists of:
• One Control and Power Supply Unit
(CPSU) (Fig. 1).
• Maximum 50 units of which one or
more chairman unit(s).
• Extension cables if required
(5m or 10m).
• Peripheral audio and/or tele-
communication equipment.
The CPSU is the heart of the discussion
system which controls the microphones
of the chairman and delegate units as
well as providing facilities for audio
inputs and outputs. It also supplies the
power for the CPSU itself, chairman
unit(s) and delegate unit(s).
A delegate unit enables participants to
actively join in a discussion (i.e. speaking
and listening) by means of a microphone,
controlled by an on/off button and a
built-in loudspeaker or external
headphone.
A chairman unit has the same function
as a delegate unit with the addition of a
'Priority' button, that enables its operator
to control the debate by temporary or
permanently overruling and muting all
active microphones, depending on an
internal setting in the chairman unit.
9
