RF range
•
Sat-IF frequency range 950 - 2150 MHz
•
Input level ranges 43 - 83 dBµV
•
Reception threshold (EB/NO) < 4.5 dB
TV system digital
•
Modulation, FEC, demultiplexer DVB-S standard
•
Video resolution CCIR 601 (720 x 576)
•
Input data rate 2 - 45 Msymbol/s
•
Bit rate 1.5 - 15 MBit/s
•
Video voltage/impedance 1 V/75 Ohm
•
S/N > 53 dB
•
Audio decoding MPEG-1/2, layers 1+2
•
Bit rate 32/44.1/48 kHz
•
Audio frequency range 0.04 - 20 kHz
CPU/Memory
•
32 bit RISC CPU 60 MHz clock rate (internal)
•
FLASH 2 MByte
•
DRAM 2 MByte
•
SDRAM 8 MByte
Power supply
•
Supply voltage 230 V (+10/-15%) / 50 Hz
•
Power consumption LNB = 400mA/18V 22 W max (19 W typ.)
•
Power consumption without LNB 12 W max (10 W typ.)
•
Power consumption in standby 2.5 W max (< 2 W typ.)
Connections
•
Sat-IF input/output F socket
•
TV/VCR SCART socket
•
Audio 2 cinch sockets
Software update
•
via data interface separately for: a) operating programme,
b) TV channel lists,
c) radio channel lists,
d) unit adjustment
[RS 232 Sub D, 9 channel (0-modem operation)].
•
via satellite separately for: a) operating programme,
b) TV and radio channel lists.
General information
•
Unit dimensions (W x H x D in mm) 335 x 68 x 280
•
Ambient temperature +5°C to +40°C
•
Weight 2 kg
