1-4-1 E9H90FIS
FUNCTION INDICATOR SYMBOLS
< VCR Section >
Note:
If a mechanical malfunction occurs, the power is turned off. When the power comes on again after that by
pressing [ ] button, an error message is displayed on the TV screen for 5 seconds.
TV screen
When reel or capstan mechanism is not functioning
correctly
When tape loading mechanism is not functioning cor-
rectly
When cassette loading mechanism is not functioning
correctly
When the drum is not working properly
P-ON+5V Power safety detection
Led Mode Indicator Active
When reel or capstan mechanism is not
functioning correctly
“A R” is displayed on a TV screen. (Refer to Fig. 1.)
When tape loading mechanism is not
functioning correctly
“A T” is displayed on a TV screen. (Refer to Fig. 2.)
When cassette loading mechanism is not
functioning correctly
“A C” is displayed on a TV screen. (Refer to Fig. 3.)
When the drum is not working properly
“A D” is displayed on a TV screen. (Refer to Fig. 4.)
P-ON+5V Power safety detection
“A P” is displayed on a TV screen. (Refer to Fig. 5.)
A
R
SP 0:00:00
Fig. 1
A
T
SP 0:00:00
Fig. 2
A
C
SP 0:00:00
Fig. 3
A
D
SP 0:00:00
Fig. 4
A
P
SP 0:00:00
Fig. 5
