ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
Parts that are not assigned part numbers (---------) are
not available.
Tolerance of Capacitors and Resistors are noted with
the following symbols.
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
ASSY 1 996510002047 MCV CBA 1
Consists of the following:
ASSY 1a MAIN CBA 1
ASSY 1b POWER SW CBA 1
ASSY 1c DVD OPEN/CLOSE SW CBA 1
ASSY 1d 996510002060 SENSOR CBA 1
MAIN CBA
2B16 BUSH LED(F) H3700UD 1
2B17 SHIELD ASSEMBLY H9200UD 1
FL1501 996510002053 FL 7-BT-310N 1
JC1012 CHIP RES.(1608) 1/10W 0 OHM 1
JC1012 RES CHIP 1608 1/10W J 0 OHM 1
JC1301 CHIP RES.(1608) 1/10W 0 OHM 1
JC1301 RES CHIP 1608 1/10W J 0 OHM 1
JC1307 CHIP RES.(1608) 1/10W 0 OHM 1
JC1307 RES CHIP 1608 1/10W J 0 OHM 1
JC1401 CHIP RES.(1608) 1/10W 0 OHM 1
JC1401 RES CHIP 1608 1/10W J 0 OHM 1
JC1403 CHIP RES.(1608) 1/10W 0 OHM 1
JC1403 RES CHIP 1608 1/10W J 0 OHM 1
JC1602 CHIP RES.(1608) 1/10W 0 OHM 1
JC1602 RES CHIP 1608 1/10W J 0 OHM 1
JC1603 CHIP RES.(1608) 1/10W 0 OHM 1
JC1603 RES CHIP 1608 1/10W J 0 OHM 1
JC2202 CHIP RES.(1608) 1/10W 0 OHM 1
JC2202 RES CHIP 1608 1/10W J 0 OHM 1
JC2701 CHIP RES.(1608) 1/10W 0 OHM 1
JC2701 RES CHIP 1608 1/10W J 0 OHM 1
JC2702 CHIP RES.(1608) 1/10W 0 OHM 1
JC2702 RES CHIP 1608 1/10W J 0 OHM 1
JC2802 CHIP RES.(1608) 1/10W 0 OHM 1
JC2802 RES CHIP 1608 1/10W J 0 OHM 1
JK2202 996510002054 RCA JACK MSP-281V41-B(B110) 1
JK2401 996510002055 S TYPE JACK MDC-050V-2.4 LF(B110 1
JK2401 996510002056 S TYPE JACK DIN-425-01 1
JK2402 996510002055 S TYPE JACK MDC-050V-2.4 LF(B110 1
JK2402 996510002056 S TYPE JACK DIN-425-01 1
JK2403 996510002057 RCA JACK MSP-213V1-652-B NI L 1
JK2751 996500025470 RCA JACK MSP-213V1-324-B NI L 1
JK2804 996510002058 RCA JACK MSP-213V3-324-B NI L 1
JK2805 996500029501 RCA JACK MSP-382V-12 NILF 1
RS1501 996500035147
SENSOR REMOTE RECEIVER KSM-
602LU2S
1
RS1501 996500008668 REMOTE RECEIVER PIC-37042LU 1
TP301 PCB JUMPER D0.6-P7.5 1
TP302 PCB JUMPER D0.6-P15.0 1
TP452 PCB JUMPER D0.6-P30.0 1
TP502 PCB JUMPER D0.6-P7.5 1
TP505 PCB JUMPER D0.6-P10.0 1
TP506 PCB JUMPER D0.6-P5.0 1
TP507 PCB JUMPER D0.6-P13.5 1
TP513 PCB JUMPER D0.6-P5.0 1
TP751 PCB JUMPER D0.6-P9.5 1
TP754 PCB JUMPER D0.6-P19.5 1
VR1501
CARBON P.O.T. VZ067TL1 B104
PB(F)
1
X1301 XTAL 3.579545MHZ(20PPM) 1
X1301 XTAL 3.579545MHZ(20PPM) 1
X1501 XTAL 14.31M(20/15/50/49S) 1
X1501 XTAL 14.31818MHZ 1
X1502
RESONATOR XTAL 32.768KHZ
QTF38-32.768K125P15L
1
X1502 XTAL DT38 32.768KHZ 1
CAPACITORS
C1051 ELECTROLYTIC CAP. 10UF/16V M H7 1
C1052 ELECTROLYTIC CAP. 470UF/6.3V M 1
C1055 ELECTROLYTIC CAP. 47UF/16V M 1
C1056 ELECTROLYTIC CAP. 22UF/16V M 1
C1058 ELECTROLYTIC CAP. 100UF/16V M 1
C1103 ELECTROLYTIC CAP. 47UF/16V M 1
C1214 ELECTROLYTIC CAP. 100UF/6.3V M 1
C1215
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C1301 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1302
CHIP CERAMIC CAP.(1608) CH J
390PF/50V
1
C1303 PCB JUMPER D0.6-P5.0 1
C1304
CHIP CERAMIC CAP.(1608) CH J
100PF/50V
1
C1305
CHIP CERAMIC CAP.(1608) CH J
100PF/50V
1
C1307
CHIP CERAMIC CAP.(1608) B K 1UF/
10V
1
C1308
ELECTROLYTIC CAP. 47UF/6.3V M
H7
1
C1309
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C1310
ELECTROLYTIC CAP. 22UF/6.3V M
H7
1
C1311 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1312
CHIP CERAMIC CAP.(1608) B K 1UF/
10V
1
C1313 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1314
CHIP CERAMIC CAP.(1608) B K 1UF/
10V
1
C1315
CHIP CERAMIC CAP.(1608) B K 1UF/
10V
1
C1316
CHIP CERAMIC CAP.(1608) B K 1UF/
10V
1
C1317
CHIP CERAMIC CAP.(1608) B K 1UF/
10V
1
C1318
ELECTROLYTIC CAP. 22UF/6.3V M
H7
1
C1319
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1324
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1327
ELECTROLYTIC CAP. 47UF/6.3V M
H7
1
C1328 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1329
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1330 ELECTROLYTIC CAP. 1UF/50V M H7 1
