Philips DVDR3545V/37 - Page 89

20070328 1-19-2 E9H90EL
C1331
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1332 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1333
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C1336
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1339
CHIP CERAMIC CAP.(1608) B K
0.047UF/50V
1
C1340
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C1341
CHIP CERAMIC CAP.(1608) B K
0.047UF/50V
1
C1342
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C1343
ELECTROLYTIC CAP. 47UF/6.3V M
H7
1
C1346
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1348
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C1401
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C1404
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1405
ELECTROLYTIC CAP. 22UF/6.3V M
H7
1
C1406
ELECTROLYTIC CAP. 33UF/6.3V M
H7
1
C1407
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1408
CHIP CERAMIC CAP.(1608) B K
0.012UF/50V
1
C1409 ELECTROLYTIC CAP. 10UF/16V M H7 1
C1410
CHIP CERAMIC CAP.(1608) B K
2700PF/50V
1
C1411
CHIP CERAMIC CAP.(1608) B K
1000PF/50V
1
C1412
ELECTROLYTIC CAP. 4.7UF/25V M
H7
1
C1413
CHIP CERAMIC CAP.(1608) B K
6800PF/50V
1
C1422
ELECTROLYTIC CAP. 47UF/6.3V M
H7
1
C1423
ELECTROLYTIC CAP. 220UF/6.3V M
H7
1
C1424 CERAMIC CAP. B K 470PF/500V 1
C1424 CERAMIC CAP. B K 470PF/100V 1
C1425
POLYESTER FILM CAP. (PB FREE)
0.018UF/100V J
1
C1425 FILM CAP.(P) 0.018UF/50V J 1
C1425 FILM CAP.(P) 0.018UF/100V J 1
C1440
ELECTROLYTIC CAP. 0.1UF/50V M
H7
1
C1441
ELECTROLYTIC CAP. 0.1UF/50V M
H7
1
C1448
ELECTROLYTIC CAP. 4.7UF/50V M
H7
1
C1449
ELECTROLYTIC CAP. 4.7UF/50V M
H7
1
C1451 ELECTROLYTIC CAP. 47UF/16V M H7 1
C1452
ELECTROLYTIC CAP. 0.1UF/50V M
H7
1
C1453 ELECTROLYTIC CAP. 10UF/16V M H7 1
C1454 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1455
ELECTROLYTIC CAP. 22UF/6.3V M
H7
1
C1456 ELECTROLYTIC CAP. 10UF/16V M H7 1
C1457
ELECTROLYTIC CAP. 4.7UF/25V M
H7
1
C1458
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1459
ELECTROLYTIC CAP. 22UF/6.3V M
H7
1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
C1460
CHIP CERAMIC CAP.(1608) B K
4700PF/50V
1
C1461
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1462
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1463
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C1465
ELECTROLYTIC CAP. 4.7UF/25V M
H7
1
C1466
ELECTROLYTIC CAP. 220UF/6.3V M
H7
1
C1467
CHIP CERAMIC CAP.(1608) B K
0.022UF/50V
1
C1470
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C1471
ELECTROLYTIC CAP. 22UF/6.3V M
H7
1
C1472
CHIP CERAMIC CAP.(1608) B K
4700PF/50V
1
C1473
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1474
ELECTROLYTIC CAP. 4.7UF/25V M
H7
1
C1475 ELECTROLYTIC CAP. 10UF/16V M H7 1
C1476 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1483
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C1485
ELECTROLYTIC CAP. 4.7UF/25V M
H7
1
C1502 ELECTROLYTIC CAP. 220UF/6.3V M 1
C1505 ELECTROLYTIC CAP. 22UF/10V M H7 1
C1507 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1508
CHIP CERAMIC CAP.(1608) B K
0.022UF/50V
1
C1509
ELECTROLYTIC CAP. 220UF/6.3V M
H7
1
C1511 CHIP CERAMIC CAP. CH J 18PF/50V 1
C1512
CHIP CERAMIC CAP.(1608) CH J
22PF/50V
1
C1514 CHIP CERAMIC CAP. CH J 27PF/50V 1
C1515
CHIP CERAMIC CAP.(1608) CH J
22PF/50V
1
C1521 ELECTROLYTIC CAP. 47UF/25V M 1
C1522
CHIP CERAMIC CAP.(1608) B K
4700PF/50V
1
C1523
CHIP CERAMIC CAP.(1608) CH J
100PF/50V
1
C1525
CHIP CERAMIC CAP.(1608) B K
4700PF/50V
1
C1527
CHIP CERAMIC CAP.(1608) B K
0.047UF/50V
1
C1529
CHIP CERAMIC CAP.(1608) B K
0.022UF/50V
1
C1530 ELECTROLYTIC CAP. 1UF/50V M H7 1
C1531 ELECTROLYTIC CAP. 10UF/16V M H7 1
C1532 ELECTROLYTIC CAP. 10UF/16V M H7 1
C1533
ELECTROLYTIC CAP. 47UF/6.3V M
H7
1
C1534
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C1535 ELECTROLYTIC CAP. 22UF/10V M H7 1
C1536
CHIP CERAMIC CAP.(1608) B K
1000PF/50V
1
C1537
CHIP CERAMIC CAP.(1608) B K
1000PF/50V
1
C1540
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1544 ELECTROLYTIC CAP. 220UF/6.3V M 1
C1545
ELECTROLYTIC CAP. 100UF/16V M
H7
1
C1546
ELECTROLYTIC CAP. 220UF/6.3V M
H7
1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
