Philips DVDR3545V/37 - Page 90

20070328 1-19-3 E9H90EL
C1585
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C1586
ELECTROLYTIC CAP. 100UF/6.3V M
H7
1
C1587
CHIP CERAMIC CAP.(1608) B K
4700PF/50V
1
C1588 ELECTROLYTIC CAP. 100UF/6.3V H7 1
C1589
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C1706
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C1933 ELECTROLYTIC CAP. 22UF/50V M H7 1
C2222
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C2223
ELECTROLYTIC CAP. 100UF/6.3V M
H7
1
C2224
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2227
ELECTROLYTIC CAP. 100UF/6.3V M
H7
1
C2228
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2324
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2325
CHIP CERAMIC CAP.(1608) CH J
33PF/50V
1
C2326
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2327
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2328
ELECTROLYTIC CAP. 100UF/6.3V M
NP
1
C2329
CHIP CERAMIC CAP.(1608) CH J
33PF/50V
1
C2330
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2331 PCB JUMPER D0.6-P5.0 1
C2355 ELECTROLYTIC CAP. 47UF/16V M H7 1
C2363
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2391 ELECTROLYTIC CAP. 100UF/10V M 1
C2392 ELECTROLYTIC CAP. 470UF/6.3V M 1
C2401
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C2403 ELECTROLYTIC CAP. 1UF/50V M H7 1
C2423
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C2441 ELECTROLYTIC CAP. 1UF/50V M 1
C2442 ELECTROLYTIC CAP. 470UF/6.3V M 1
C2443 ELECTROLYTIC CAP. 470UF/6.3V M 1
C2461 ELECTROLYTIC CAP. 1UF/50V M H7 1
C2462 ELECTROLYTIC CAP. 470UF/6.3V M 1
C2481 ELECTROLYTIC CAP. 1UF/50V M 1
C2482 ELECTROLYTIC CAP. 470UF/6.3V M 1
C2523
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2524 ELECTROLYTIC CAP. 100UF/6.3V M 1
C2531
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C2532
ELECTROLYTIC CAP. 22UF/6.3V M
H7
1
C2535
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C2536
ELECTROLYTIC CAP. 22UF/6.3V M
H7
1
C2537
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2762 ELECTROLYTIC CAP. 10UF/16V M 1
C2766
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C2777 ELECTROLYTIC CAP. 10UF/16V M 1
C2778 PCB JUMPER D0.6-P5.0 1
C2779 PCB JUMPER D0.6-P5.0 1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
C2780
ELECTROLYTIC CAP. 100UF/6.3V M
H7
1
C2807
CHIP CERAMIC CAP.(1608) CH J
1000PF/50V
1
C2808
CHIP CERAMIC CAP.(1608) CH J
1000PF/50V
1
C2814 ELECTROLYTIC CAP. 2.2UF/50V M 1
C2818
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C2819
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C2820 ELECTROLYTIC CAP. 2.2UF/50V M 1
C2821 ELECTROLYTIC CAP. 22UF/16V M 1
C2822
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C2823 ELECTROLYTIC CAP. 2.2UF/50V M 1
C2825 ELECTROLYTIC CAP. 2.2UF/50V M 1
C2826 ELECTROLYTIC CAP. 2.2UF/50V M 1
C2827
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2828 ELECTROLYTIC CAP. 100UF/6.3V M 1
C2829
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2831 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2832 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2833 ELECTROLYTIC CAP. 100UF/6.3V M 1
C2837
CHIP CERAMIC CAP.(1608) CH J
33PF/50V
1
C2838
CHIP CERAMIC CAP.(1608) CH J
33PF/50V
1
C2839 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2840
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2841 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2842 ELECTROLYTIC CAP. 330UF/10V M 1
C2844 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2845
CHIP CERAMIC CAP.(1608) CH J
270PF/50V
1
C2846 ELECTROLYTIC CAP. 470UF/6.3V M 1
C2847
CHIP CERAMIC CAP.(1608) CH J
47PF/50V
1
C2848
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C2850 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2851
CHIP CERAMIC CAP.(1608) CH J
270PF/50V
1
C2852
CHIP CERAMIC CAP.(1608) CH J
47PF/50V
1
C2853 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2854 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2863 ELECTROLYTIC CAP. 10UF/16V M 1
C2864 ELECTROLYTIC CAP. 10UF/16V M H7 1
C2922 ELECTROLYTIC CAP. 4.7UF/50V M 1
C5042
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C5046 ELECTROLYTIC CAP. 470UF/6.3V M 1
C5047 ELECTROLYTIC CAP. 100UF/6.3V M 1
C5060 CARBON RES. 1/6W J 68K OHM 1
C5060 CARBON RES. 1/4W J 68K OHM 1
C5063 CARBON RES. 1/6W J 47K OHM 1
C5063 CARBON RES. 1/4W J 47K OHM 1
C5064 CARBON RES. 1/6W J 68K OHM 1
C5064 CARBON RES. 1/4W J 68K OHM 1
C5065 CARBON RES. 1/6W J 47K OHM 1
C5065 CARBON RES. 1/4W J 47K OHM 1
CONNECTORS
CN1101
FFC CONNECTOR 30PIN IMSA-
9615S-30A-PP-A
1
CN1101
FFC CONNECTOR 30PIN 00 6232
030 006 800+
1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
