Philips DVDR3545V/37 - Page 91

20070328 1-19-4 E9H90EL
CN1102
PH CONNECTOR TOP 2P B2B-PH-K-
S (LF)(SN)
1
CN2201
WIRE ASSEMBLY FFC 30P 30 150
WHITE
1
CN2204
WIRE ASSEMBLY FFC 30P 30 150
WHITE
1
CN2609
FE CONNECTOR TOP 8P 08FE-BT-
VK-N
1
CN2610
FFC CONNECTOR IMSA-9615S-20A-
PP-A
1
CN2610
CONNECTOR PRINT MES 00 6232
020 006 800+
1
CN2611
FFC CONNECTOR IMSA-9615S-18A-
PP-A
1
CN2611
CONNECTOR FPC 18P 00 6232 018
006 800+
1
DIODES
D1052 ZENER DIODE MTZJT-7710B 1
D1052 DIODE ZENER 10BSB-T26 1
D1052 ZENER DIODE DZ-10BSBT265 1
D1082 PCB JUMPER D0.6-P5.0 1
D1083 ZENER DIODE MTZJT-7718B 1
D1083 DIODE ZENER 18BSB-T26 1
D1083 ZENER DIODE DZ-18BSBT265 1
D1085 RECTIFIER DIODE 1N4005 1
D1085 RECTIFIER DIODE 1N4005 1
D1100 SWITCHING DIODE 1SS133(T-77) 1
D1100 DIODE SWITCHING 1N4148-F0021 1
D1100 SWITCHING DIODE 1N4148M 1
D1101 SWITCHING DIODE 1SS133(T-77) 1
D1101 DIODE SWITCHING 1N4148-F0021 1
D1101 SWITCHING DIODE 1N4148M 1
D1106 ZENER DIODE MTZJT-774.3C 1
D1106 DIODE ZENER 4V3BSC-T26 1
D1106 ZENER DIODE DZ-4.3BSCT265 1
D1108 SWITCHING DIODE 1SS133(T-77) 1
D1108 DIODE SWITCHING 1N4148-F0021 1
D1108 SWITCHING DIODE 1N4148M 1
D1109 SWITCHING DIODE 1SS133(T-77) 1
D1109 DIODE SWITCHING 1N4148-F0021 1
D1109 SWITCHING DIODE 1N4148M 1
D1110 RECTIFIER DIODE 1N4005 1
D1110 RECTIFIER DIODE 1N4005 1
D1111 RECTIFIER DIODE 1N4005 1
D1111 RECTIFIER DIODE 1N4005 1
D1501 SWITCHING DIODE 1SS133(T-77) 1
D1501 DIODE SWITCHING 1N4148-F0021 1
D1501 SWITCHING DIODE 1N4148M 1
D1555 LED MIE-534A2 1
D1555 LED SIR-563ST3F P 1
D1555 LED SIR-563ST3F Q 1
D1562 LED(YELLOW) 204YD/E 1
D1563 LED(YELLOW) 204YD/E 1
D1701 ZENER DIODE MTZJT-7733B 1
D1701 DIODE ZENER 33BSB-T26 1
D1701 ZENER DIODE DZ-33BSBT265 1
D2013 RECTIFIER DIODE RL201 1
D2221 SWITCHING DIODE 1SS133(T-77) 1
D2221 DIODE SWITCHING 1N4148-F0021 1
D2221 SWITCHING DIODE 1N4148M 1
D2223 SWITCHING DIODE 1SS133(T-77) 1
D2223 DIODE SWITCHING 1N4148-F0021 1
D2223 SWITCHING DIODE 1N4148M 1
D2230 PCB JUMPER D0.6-P5.0 1
D2231 SWITCHING DIODE 1SS133(T-77) 1
D2231 DIODE SWITCHING 1N4148-F0021 1
D2231 SWITCHING DIODE 1N4148M 1
D2603 RECTIFIER DIODE 1N4005 1
D2603 RECTIFIER DIODE 1N4005 1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
D2604 PCB JUMPER D0.6-P10.0 1
D2771 ZENER DIODE MTZJT-775.1B 1
D2771 DIODE ZENER 5V1BSB-T26 1
D2771 ZENER DIODE DZ-5.1BSBT265 1
D2801 ZENER DIODE MTZJT-775.1B 1
D2801 DIODE ZENER 5V1BSB-T26 1
D2801 ZENER DIODE DZ-5.1BSBT265 1
D2802 ZENER DIODE MTZJT-775.1B 1
D2802 DIODE ZENER 5V1BSB-T26 1
D2802 ZENER DIODE DZ-5.1BSBT265 1
D2803 ZENER DIODE MTZJT-775.1B 1
D2803 DIODE ZENER 5V1BSB-T26 1
D2803 ZENER DIODE DZ-5.1BSBT265 1
D2804 ZENER DIODE MTZJT-775.1B 1
D2804 DIODE ZENER 5V1BSB-T26 1
D2804 ZENER DIODE DZ-5.1BSBT265 1
D2805 ZENER DIODE MTZJT-775.1B 1
D2805 DIODE ZENER 5V1BSB-T26 1
D2805 ZENER DIODE DZ-5.1BSBT265 1
D2806 ZENER DIODE MTZJT-775.1B 1
D2806 DIODE ZENER 5V1BSB-T26 1
D2806 ZENER DIODE DZ-5.1BSBT265 1
D2807 ZENER DIODE MTZJT-775.1B 1
D2807 DIODE ZENER 5V1BSB-T26 1
D2807 ZENER DIODE DZ-5.1BSBT265 1
D2808 ZENER DIODE MTZJT-775.1B 1
D2808 DIODE ZENER 5V1BSB-T26 1
D2808 ZENER DIODE DZ-5.1BSBT265 1
D3004 SWITCHING DIODE 1SS133(T-77) 1
D3004 DIODE SWITCHING 1N4148-F0021 1
D3004 SWITCHING DIODE 1N4148M 1
D3005 DIODE 1N5397-B 1
D3005 DIODE 1N5397BD 1
ICS
IC1301 996500024158 IC Y/C/A LA71205M-MPB-E 1
IC1451 996500024159 IC HIFI LA72670BM-MPB-E 1
IC1501 996510004026 IC SYSCON MN101D10FYM1 1
IC1571 996500027576
VFD DRIVER/CONTROLLER IC
PT6313-S-TP(L)
1
IC1571 996500027577 VFD DRIVER IC SC16313G 1
IC2404 996500023989 DRIVER FOR DVD MM1636XWRE 1
IC2405 996500023981 DRIVER FOR DVD MM1637XVBE 1
IC2406 996500023980
IC ANALOG MULTIPLEXER
CD4053BNSR
1
IC2406 996500029478 IC SWITCH TC4053BF(EL N F) 1
IC2503 996500029020
VOLTAGE REGULATOR
PQ070XF01SZH
1
IC2504 996500029020
VOLTAGE REGULATOR
PQ070XF01SZH
1
IC2801 996510002049 IC SWITCHING CD4052BNSR 1
IC2801 996510002050 IC SWITCHING TC4052BF(ELNF) 1
IC2803 996510002051 IC OP AMP UTC4580E 1
IC2804 996500029479 IC OP AMP KIA4558P/P 1
IC2804 996500027574 IC OP AMP UTC4558 1
IC2805 996510002052 VIDEO SWITCH MM1697AJBE 1
IC5002 996500023980
IC ANALOG MULTIPLEXER
CD4053BNSR
1
IC5002 996500029478 IC SWITCH TC4053BF(EL N F) 1
IC5004 996500029020
VOLTAGE REGULATOR
PQ070XF01SZH
1
COILS
L1251 PCB JUMPER D0.6-P5.0 1
L1303 INDUCTOR(100UH K) LAP02TA101K 1
L1304
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP
1
L1304 CHOKE COIL 47UH 1
L1304 CHOKE COIL 47UH-K 1
L1305 CHIP RES.(1608) 1/10W 0 OHM 1
L1305 RES CHIP 1608 1/10W J 0 OHM 1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
