Philips DVDR3545V/37 - Waveforms

1-14-1
WAVEFORMS
WF9
AUDIO(L)-OUT
Pin 17 of CN2201
1V 0.5ms
WF7
VIDEO-Cb
Pin 3 of CN2201
0.2V 20 µ s
WF8
VIDEO-Cr
Pin 5 of CN2201
0.2V 20 µ s
SPDIF 1V 0.1 µ s
WF10 Pin 3 of CN2204
WF4 Pin 7 of CN2201
VIDEO-Y 0.2V 20 µ s
WF5 Pin 9 of CN2201
VIDEO-C 0.2V 20 µ s
WF6 Pin 2 of IC2406
VIDEO-CVBS 0.5V 20 µ s
NOTE:
Input: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL)
WF3
WF1
UPPER
WF2
WF2
LOWER
TP751
TP302
UPPER
LOWER
TP302
TP301
V-OUT 0.5V
50
µs RF-SW 5V
C-PB
RF-SW 5V 5m
s
0.2V
WF1
TP751
V-OUT E-E 0.2V 20 µs
WD4NWF
