1-7-3 E9H90SNA
VIDEO-COM Video Head Common Terminal
VIDEO-IN Composite Video Signal Input
VIDEO-MUTE Video Mute Control Signal
VIDEO-OUT Composite Video Signal Output
VIDEO-Pb/Cb Component Video Signal (Pb/Cb)
VIDEO-Pb/Cb-
OUT
Component Video Signal (Pb/Cb)
Output
VIDEO-Pr/Cr Component Video Signal (Pr/Cr)
VIDEO-Pr/Cr-
OUT
Component Video Signal (Pr/Cr)
Output
VIDEO-SW1 Video Input Select Signal 1
VIDEO-SW2 Video Input Select Signal 2
VIDEO-SW3 Video Input Select Signal 3
VIDEO-Y(I)
S-Video (Luminance)
Signal (Interlace)
VIDEO-Y(I)-
OUT
S-Video (Luminance) Signal
(Interlace / Progressive) Output
VIDEO-Y(I/P)
Component Video (Luminance)
Signal (Interlace / Progressive)
VIDEO-Y(I/P)-
OUT
Component Video (Luminance)
Signal (Interlace / Progressive)
Output
VIDEO-Y/
CVBS-IN
S-Video (Luminance) / Composite
Video Signal
VRI Servo Standard Voltage Input
VRO Servo Standard Voltage Output
VSS Ground
XI Main Clock Input
XO Main Clock Output
Y-IN2 S-Video (Luminance) Signal
YCA-CS YCA IC Chip Select
YCA-SCL YCA IC Serial Clock
YCA-SDA YCA IC Serial Data
Signal Name Function
