1-17-2 E9H90PIN
58 OUT
VIDEO-
SW2
Video Input Select Signal 2
59 OUT
VIDEO-
SW1
Video Input Select Signal 1
60 OUT
AUDIO-
SW2
Audio Input Select Signal 2
61 OUT
AUDIO-
SW1
Audio Input Select Signal 1
62 OUT
DTV/
ANALOG
DTV/ANALOG Select Signal
63 - NU Not Used
64 - NU Not Used
65 IN
D-PFG Drum PG/FG Input Signal
66 - NU Not Used
67 IN
C-FG
Capstan Motor Rotation
Detection Pulse
68 -
AFG Ground
69 OUT
VRO
Servo Standard Voltage
Output
70 IN
VRI Servo Standard Voltage Input
71 -
AVss Ground
72 IN
CTLA CTL Amp. AC Ground
73 IN ADVV Power Supply
74
IN/
OUT
CTL (+)
Playback/Record Control
Signal (+)
75
IN/
OUT
CTL (-)
Playback/Record Control
Signal (-)
76 OUT
CTL
Amp. Output Control Signal for
Test Point
77 OUT
FAN-
CONT
Fan Motor Control Signal
78 IN
Hi-Fi/
NOR-IN
Audio Mode Input HiFi=”L”/
Normal=”H”
79 IN
DVD
POWER-
SAFETY
DVD Power Supply Safety
Signal
80 IN
VCR
POWER-
SAFETY
VCR Power Supply Safety
Signal
81 IN
END-S
Tape End Position Detect
Signal
82 IN AFC
Automatic Frequency Control
Signal
83 IN
V-ENV
Video Envelope Comparator
Signal
84 IN
PG-
DELAY
Video Head Switching Pulse
Signal Adjusted Voltage
85 IN
KEY-2 Key Data Input 2
86 IN
KEY-1 Key Data Input 1
87 IN
LD-SW
Deck Mode Position Detector
Signal
Pin
No.
IN/
OUT
Signal
Name
Function
88 IN
ST-S
Tape Start Position Detector
Signal
89 IN
DVD
POWER-
SAFETY2
DVD Power Supply Safety
Signal
90 OUT
DTV1.05V
-CONT
DTV1.05 Control Signal
91 OUT
BUS-
CONT
BUS Control Signal
92 OUT
POWER-
LED
Power LED Control Signal
93 OUT
POWER-
LED
Power LED Control Signal
94 OUT VCR-LED VCR LED Control Signal
95 OUT VCR-LED VCR LED Control Signal
96 OUT DVD-LED DVD LED Control Signal
97 OUT DVD-LED DVD LED Control Signal
98 OUT
C-ROTA
Color Phase Rotary
Changeover Signal
99 OUT
H-A-SW
Video Head Amp Switching
Pulse
100 IN
H-A-
COMP
Head Amp Comparator Signal
Pin
No.
IN/
OUT
Signal
Name
Function
