1-4-1 H9622FIS
FUNCTION INDICATOR SYMBOLS
Note:
If a mechanical malfunction occurs, the power is turned off. When the power comes on again after that by
pressing [STANDBY-ON] button, an error message is displayed on the TV screen for 5 seconds.
TV screen
When reel and capstan mechanism is not functioning
correctly
When tape loading mechanism is not functioning cor-
rectly
When cassette loading mechanism is not functioning
correctly
When the drum is not working properly
Led Mode Indicator Active
When reel and capstan mechanism is not
functioning correctly
“EJECT A R” is displayed on a TV screen. (Refer to Fig. 1.)
When tape loading mechanism is not func-
tioning correctly
“EJECT A T” is displayed on a TV screen. (Refer to Fig. 2.)
When cassette loading mechanism is not
functioning correctly
“EJECT A C” is displayed on a TV screen. (Refer to Fig. 3.)
When the drum is not working properly
“EJECT A D” is displayed on a TV screen. (Refer to Fig. 4.)
EJECT
A
R
Fig. 1
EJECT
A
T
Fig. 2
EJECT
A
C
Fig. 3
EJECT
A
D
Fig. 4
