Philips DVP620VR/00 - ELECTRICAL PARTS LIST

1-18-1
ELECTRICAL PARTS LIST
MISCELLANEOUS
9965 000 25718 DVD MAIN CBA UNIT
9965 000 23969 PSV CBA (PSU, JUNCTION & JACK)
9965 000 25719 MCV CBA (MAIN, SENSOR, POWER SW,
DVD OPEN/CLOSE & AFV PCB ASSY)
9965 000 24118 SENSOR CBA
9965 000 23977 AFV PCB ASSEMBLY CPD0500/9701
MCV CBA UNIT
MCV CBA UNIT consists of MAIN CBA, POWER SW CBA, DVD OPEN/CLOSE
CBA, SENSOR CBA AND AFV PCB ASSEMBLY
MAIN CBA
MISCELLANEOUS
CN051 9965 000 20908 CONN BASE 18P TUC-P18P-B1
JK101 9965 000 20716 RGB CONNECTOR MRC-021V-03
JK751 9965 000 13039 RCA JACK 0.01282V-12 PBSN
JK752 4822 265 11659 RCA JACK(YELLOW) MSP-281V4-B
JK753 4822 265 11661 RCA JACK(WHITE) MSP-281V1-B
JK754 9965 000 00423 MSP-281V3-A RCA JACK(RED)
JK1202 9965 000 15322 RCA JACK(BLACK) MSP-281V2-B
JK1401 9965 000 15323 S TYPE JACK MDC-050V-2.4
JW006 9965 000 23991 CABLE, 27P FFC/P1.00/260
JW007 9965 000 23992 CABLE, 20P FFC/P1.00/170
PS502 9965 000 12189 PHOTO INTERRUPTER RPI-302C70
RM2001 9965 000 10857 REMOTE RECEIVER
SW501 4822 276 13954 TACT SWITCH KSM0614B
SW501 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW503 4822 276 13954 TACT SWITCH KSM0614B
SW504 4822 276 13954 TACT SWITCH KSM0614B
SW504 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW506 9965 000 16625 LEAF SWITCH MXS01830MVP0
SW507 9965 000 23359 ROTARY MODE SWITCH SSS-53MD
SW601 4822 276 13954 TACT SWITCH KSM0614B
SW601 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW602 4822 276 13954 TACT SWITCH KSM0614B
SW602 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW603 4822 276 13954 TACT SWITCH KSM0614B
SW603 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW604 4822 276 13954 TACT SWITCH KSM0614B
SW604 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW605 4822 276 13954 TACT SWITCH KSM0614B
SW605 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW2005 4822 276 13954 TACT SWITCH KSM0614B
SW2005 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW2021 4822 276 13954 TACT SWITCH KSM0614B
SW2021 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW2022 4822 276 13954 TACT SWITCH KSM0614B
SW2022 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
TU701 9965 000 23391 TUNER UNIT TMDG2-861A
X301 9965 000 05629 X’TAL 4.433619MHZ
X501 9965 000 12194 X’TAL 12.000MHZ
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM)
CAPACITORS
C402 9965 000 23975 FILM CAP 0.018UF /100V J
C403 9965 000 06523 CERAMIC CAP. B K 470PF/100V
RESISTORS
R066 9965 000 25725 CEMENT RESISTOR 5W J 4.7 OHM
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B
COILS & FILTERS
L053 4822 157 10649 100UH
L101 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L122 9965 000 05627 CHOKE COIL 47UH-K
L122 * 9965 000 23990 CHOKE COIL 47UH-K
L251 9965 000 08652 INDUCTOR 5.6UH-K-26T
L302 4822 157 10649 100UH
L402 9965 000 05705 INDUCTOR 47UH-K-5FT
L451 9965 000 05705 INDUCTOR 47UH-K-5FT
L501 4822 157 10649 100UH
L503 9965 000 08629 INDUCTOR 1.8UH-K-26T
L701 4822 157 11511 15UH-K-26T
L1251 9965 000 15331 INDUCTOR 0.47UH-K-26T
L1351 4822 157 10649 100UH
L1521 9965 000 05627 CHOKE COIL 47UH-K
L1521 * 9965 000 23990 CHOKE COIL 47UH-K
L2001 4822 157 10649 100UH
DIODES
D051 4822 130 31933 1N5061
D052 4822 130 31933 1N5061
D054 9965 000 09283 ZENER DIODE DZ-10BSBT265
D056 9965 000 23356 ZENER DIODE DZ-18BSBT265
D057 4822 130 31933 1N5061
D101 9965 000 12178 ZENER DIODE DZ-11BSAT265
D102 9965 000 12178 ZENER DIODE DZ-11BSAT265
D103 9965 000 12178 ZENER DIODE DZ-11BSAT265
D104 9965 000 12178 ZENER DIODE DZ-11BSAT265
D105 9965 000 12178 ZENER DIODE DZ-11BSAT265
D106 9965 000 12178 ZENER DIODE DZ-11BSAT265
D107 9965 000 12178 ZENER DIODE DZ-11BSAT265
D108 9965 000 12178 ZENER DIODE DZ-11BSAT265
D109 9965 000 12178 ZENER DIODE DZ-11BSAT265
D110 9965 000 12178 ZENER DIODE DZ-11BSAT265
D115 9965 000 12178 ZENER DIODE DZ-11BSAT265
D118 9965 000 12178 ZENER DIODE DZ-11BSAT265
D119 9965 000 12178 ZENER DIODE DZ-11BSAT265
D121 9965 000 12178 ZENER DIODE DZ-11BSAT265
D301 4822 130 30621 1N4148
D502 9965 000 08623 LED(GREEN) 204-10GD/S957
D503 9965 000 08623 LED(GREEN) 204-10GD/S957
D510 4822 130 30621 1N4148
