2-1-1 U29PMEN
STANDARD MAINTENANCE
Service Schedule of Components
This maintenance chart shows you the standard of replacement and cleaning time for each part.
Because those may replace depending on environment and purpose for use, use the chart for reference.
Notes:
1.Clean all parts for the tape transport (Upper Drum with Video Head / Pinch Roller / ACE Head / FE Head) using
90% lsopropyl Alcohol.
2.After cleaning the parts, do all DECK ADJUSTMENTS.
3.For the reference numbers listed above, refer to Deck Exploded Views.
h: Hours : Cleaning I: Replace
Deck Periodic Service Schedule
Ref.No. Part Name 1,000 h 2,000 h 3,000 h 4,000 h
B2
Cylinder Assembly
II
B3
Loading Motor Assembly
I
B8 Pulley Assembly I
I
B587
Tension Lever Assembly
II
B31
ACE Head Assembly
I
B573, B574 Reel (SP)(D2), Reel (TU)(D2)
I
B37
Capstan Motor
II
B52
Cap Belt
II
B73 FE Head
I
B133, B134
Idler Gear, Idler Arm
II
B410
Pinch Arm(A) Assembly
II
B414 M Brake (SP) Assembly II
B416
M Brake (TU) Assembly
II
B525
LDG Belt
II
B569
(2 head only)
Cam Holder
II
B593
(4 head,
4 head HiFi
only)
Cam Holder Assembly
II
