Philips DVP620VR/00 - ELECTRICAL PARTS LIST

1-18-1
ELECTRICAL PARTS LIST
MISCELLANEOUS
9965 000 23968 DVD MAIN CBA UNIT
9965 000 23970 MCV CBA UNIT /00
9965 000 24012 MCV CBA UNIT /02
9965 000 24017 MCV CBA UNIT /05
9965 000 23969 PSV CBA UNIT /00/02
9965 000 24016 PSV CBA UNIT /05
9965 000 23977 AFV PCB ASSEMBLY CPD0500/9701
9965 000 23974 SENSOR CBA
MCV CBA UNIT
MCV CBA UNIT consists of MAIN CBA, POWER SWITCH CBA, DVD OPEN/
CLOSE CBA and SENSOR CBA.
MAIN CBA
MISCELLANEOUS
9965 000 23977 AFV PCB ASSEMBLY CPD0500/9701
CN051 9965 000 20908 CONN BASE 18P TUC-P18P-B1
JK101 9965 000 20716 RGB CONNECTOR MRC-021V-03
JK1202 9965 000 15322 RCA JACK(BLACK) MSP-281V2-B
JK1401 9965 000 15323 S TYPE JACK MDC-050V-2.4
JK751 9965 000 13039 RCA JACK 0.01282V-12 PBSN
JK752 4822 265 11659 RCA JACK(YELLOW) MSP-281V4-B
JK753 4822 265 11661 RCA JACK(WHITE) MSP-281V1-B
JK754 9965 000 00423 MSP-281V3-A RCA JACK(RED)
JW006 9965 000 23991 CABLE, 27P FFC/P1.00/260
JW007 9965 000 23992 CABLE, 20P FFC/P1.00/170
PS502 9965 000 12189 PHOTO INTERRUPTER RPI-302C70
RM2001 9965 000 10857 REMOTE RECEIVER
SW2005 4822 276 13954 KSM0614B
SW2005 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW2005 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW2021 4822 276 13954 KSM0614B
SW2021 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW2021 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW2022 4822 276 13954 KSM0614B
SW2022 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW2022 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW501 4822 276 13954 KSM0614B
SW501 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW501 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW502 4822 276 13954 KSM0614B
SW502 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW502 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW503 4822 276 13954 KSM0614B
SW503 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW503 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW504 4822 276 13954 KSM0614B
SW504 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW504 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW506 9965 000 16625 LEAF SWITCH MXS01830MVP0
SW507 9965 000 23359 ROTARY MODE SWITCH SSS-53MD
SW601 4822 276 13954 KSM0614B
SW601 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW601 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW602 4822 276 13954 KSM0614B
SW602 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW602 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW603 4822 276 13954 KSM0614B
SW603 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW603 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW604 4822 276 13954 KSM0614B
SW604 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW604 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
SW605 4822 276 13954 KSM0614B
SW605 4822 276 14127 SKQSAF001A (ALTERNATIVE)
SW605 9965 000 19590 TC-1104(H=9.5) (ALTERNATIVE)
TU701 9965 000 23361 TUNER UNIT TMDG2-661A /00
TU701 9965 000 23395 TUNER UNIT TMDZ2-761A /02
TU701 9965 000 23386 TUNER UNIT TMDG2-662A /05
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B
X301 9965 000 05629 X’TAL 4.433619MHZ
X301 4822 242 10695 4 433 619 MHZ (ALTERNATIVE)
X501 9965 000 12194 X’TAL 12.000MHZ
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM)
X502 9965 000 19592 X’TAL 32.768KHZ(20PPM) (ALTERNATIVE)
CAPACITORS
C056 9965 000 14863 ELCAP 47UF/25V M
C056 9965 000 19553 ELCAP. 47UF/25V M (ALTERNATIVE)
C057 9965 000 09762 ELCAP 220UF/6.3V M H7
C057 9965 000 19554 ELCAP. 10UF/16V M (ALTERNATIVE)
C058 9965 000 09834 CHIP CAP CG J 220PF/50V
C059 9965 000 09843 CAP(AX) SL J 56PF/50V
C059 9965 000 09844 CAP(AX) B J 1000PF/50V (ALTERNATIVE)
C063 9965 000 15244 ELCAP 47UF/16V M
C063 9965 000 19557 ELCAP. 47UF/16V M (ALTERNATIVE)
C104 9965 000 15246 ELCAP 100UF/16V M
C107 4822 124 42027 470UF20% 6,3V
C107 9965 000 19558 ELCAP. 470UF/6.3V M (ALTERNATIVE)
C117 9965 000 15289 ELCAP 1UF/50V M
C117 9965 000 19559 ELCAP. 1UF/50V M (ALTERNATIVE)
C121 9965 000 15291 ELCAP 1UF/50V M H7
C122 9965 000 15291 ELCAP 1UF/50V M H7
C123 9965 000 15291 ELCAP 1UF/50V M H7
C124 4822 124 42027 470UF20% 6,3V
C124 9965 000 19558 ELCAP. 470UF/6.3V M (ALTERNATIVE)
C125 4822 124 42027 470UF20% 6,3V
C125 9965 000 19558 ELCAP. 470UF/6.3V M (ALTERNATIVE)
C126 4822 124 42027 470UF20% 6,3V
C126 9965 000 19558 ELCAP. 470UF/6.3V M (ALTERNATIVE)
C127 9965 000 09762 ELCAP 220UF/6.3V M H7
C127 9965 000 19554 ELCAP. 10UF/16V M (ALTERNATIVE)
C128 9965 000 15300 ELCAP 22UF/6.3V M H7
C129 9965 000 15293 ELCAP 100UF/16V M H7 /00/05
