2-7-1
MECHANICAL PARTS LIST - VCR MECHANISM
B2 9965 000 23381 CYLINDER ASSEMBLY MK12.5 PAL 6HD
B2 9965 000 24006 CYLINDER ASY MK12.5 PAL 6HD(V)
B3 9965 000 23363 LOADING MOTOR ASSEMBLY MK12.5
B5 9965 000 24007 SLIDE PLATE MK12.5
B8 9965 000 16631 PULLEY ASSEMBLY(HI) MK12
B9 9965 000 23364 MOVING GUIDE S P.P MK12.5
B10 9965 000 23365 MOVING GUIDE T P.P MK12.5
B11 9965 000 16634 LOADING ARM(TU) ASSEMBLY MK12
B12 9965 000 16635 LOADING ARM(SP) ASSEMBLY MK12
B31 9965 000 23366 AC HEAD ASSEMBLY MK12.5
B35 9965 000 23382 TAPE GUIDE ARM ASSEMBLY MK12.5
B37 9965 000 23367 CAPSTAN MOTOR 288/VCZC1301
B52 9965 000 08593 CAP BELT MK10
B73 9965 000 12210 FE HEAD ASSEMBLY MK11
B73 9965 000 19627 FE HEAD(MK12) VTR-1X2ERS11-155
B73 9965 000 12210 FE HEAD ASSEMBLY MK11
B74 9965 000 08555 PRISM MK10
B86 9965 000 16639 F BRAKE ASSEMBLY(HI) MK12
B121 9965 000 16640 WORM MK12
B126 9965 000 18128 PULLEY MK12
B133 9965 000 23368 IDLER ASSEMBLY(HI) MK12.5
B148 4822 462 11189 TG CAP
B300 9965 000 16643 C DRIVE LEVER(TU) MK12
B303 9965 000 18129 F DOOR OPENER MK12
B313 9965 000 16645 C DRIVE SPRING MK12
B347 9965 000 08445 GUIDE HOLDER MK10
B354 9965 000 18130 SLIDER(TU) MK12
B355 9965 000 19630 SLIDER(SP) MK12
B359 9965 000 08449 CLEANER LEVER MK10
B360 9965 000 06561 CLEANER ROLLER MK9
B361 9965 000 08450 CL POST MK10
B410 9965 000 23370 PINCH ARM(A) ASSEMBLY(6) MK12.5
B410 9965 000 16648 PINCH ARM(A) ASSEMBLY(4) MK12
B411 9965 000 16649 PINCH SPRING MK12
B414 9965 000 17218 M BRAKE(SP) ASSEMBLY(HI) MK12
B416 9965 000 16651 M BRAKE(TU) ASSEMBLY(HI) MK12
B417 9965 000 24008 TENSION SPG(3002645) MK12.5
B425 9965 000 08457 LOCK LEVER SPRING MK10
B482 9965 000 16653 CASSETTE PLATE MK12
B483 9965 000 16654 LOCK LEVER MK12
B487 9965 000 16655 BAND BRAKE(SP) MK12
B488 9965 000 18145 MODE LEVER(HI) MK12
B488 9965 000 24009 MODE LEVER(HI) MK12.5
B491 9965 000 16657 CAM GEAR(A)(HI) MK12
B492 9965 000 19636 MODE GEAR(LM) MK12
B494 9965 000 16659 C DOOR OPENER MK12
B499 9965 000 16660 T LEVER HOLDER MK12
B501 9965 000 16661 WORM HOLDER MK12
B501 9965 000 24010 WORM HOLDER(R) MK12
B507 9965 000 05342 REEL WASHER MK9 5*2.1*0.5
B508 9965 000 17219 S BRAKE SPRING(HI) MK12
B513 4822 532 13158 P.S.W. F
B514 9965 000 08641 SCREW RACK MK10
B516 9965 000 05342 REEL WASHER MK9 5*2.1*0.5
B518 4822 532 13159 P.S.W. 1.6X4.0X0.5T
B521 9965 000 17220 REV BRAKE SPG(HI) MK12
B522 9965 000 08483 TG POST ASSEMBLY MK10
B525 9965 000 12230 LDG BELT MK11
B529 9965 000 08504 CLEANER ASSEMBLY MK10
B551 9965 000 17221 FF ARM(HI) MK12
B553 9965 000 12233 REV SPRING MK11
B555 9965 000 16663 RACK ASSEMBLY MK12
B557 9965 000 08519 MOTOR PULLEY U5
B558 9965 000 23373 LOADING MOTOR M31E-1 R-14 7401
B559 9965 000 16664 CLUTCH ASSEMBLY(HI) MK12
B562 9965 000 16665 C DRIVE LEVER(SP) MK12
B563 9965 000 16666 SLIDER SHAFT MK12
B564 9965 000 16667 M GEAR(HI) MK12
B565 9965 000 16668 SENSOR GEAR(HI) MK12
B567 9965 000 16669 PINCH ARM(B) MK12
B568 9965 000 16670 BT ARM MK12
B571 4822 532 13159 P.S.W. 1.6X4.0X0.5T
B572 4822 532 13159 P.S.W. 1.6X4.0X0.5T
B573 9965 000 12241 REEL S MK11
B574 9965 000 12376 REEL T MK10
B578 9965 000 12243 TR GEAR A MK10
B579 9965 000 16671 TR GEAR B MK12
B580 9965 000 19638 TR GEAR C MK12
B581 9965 000 16673 CENTER GEAR MK11
B582 9965 000 23374 TR GEAR SPRING MK10
B583 9965 000 17201 CAM WASHER MK12
B585 9965 000 13687 PSW(317505) MK11
B587 9965 000 16674 TENSION LEVER ASSEMBLY MK12
B590 9965 000 18132 BRAKE ARM(TU) MK12
B591 9965 000 17210 BAND BRAKE(TU) MK12
B592 9965 000 16678 TG POST MK10
L1051 9965 000 05359 SCREW, M2.6X6 PAN HEAD+
L1053 9965 000 05375 SCREW, M2.6X8 WASHER HEAD+
L1151 9965 000 08642 SCREW, SEMS M2.6X4 PAN +
L1191 9965 000 05375 SCREW, M2.6X8 WASHER HEAD+
L1321 4822 502 14009 M 3 X 6
L1322 9965 000 08645 SCREW, B-TIGHT M2.3X4 BIND HEAD+
L1341 9965 000 23375 SCREW, P-TIGHT M2X6 PAN HEAD+
L1406 9965 000 08643 AC HEAD SCREW MK9
L1450 4822 502 14671 SCREW M2.6X5
L1466 9965 000 05364 SCREW, M2.6X6 BIND HEAD+
L1467 9965 000 23376 SCREW M2.6X5 WASHER HEAD+
Note: Only the parts mentioned in this list are normal service spare parts.
