Philips DVP620VR/00 - WIRING DIAGRAM < DVD SECTION >

WIRING DIAGRAM < DVD SECTION >
H9723WID
1-14-2
DVD MECHA
DVD MAIN CBA UNIT
TO MAIN CBA CN1051 (JW001) TO MAIN CBA CN1601 (JW002)
CN301
TRAY-IN
DRIVE CBA
M
SLED MOTOR
M
SPINDLE MOTOR
EV+1.2V EV+1.2V
EV+3.3V
EV+3.3V EV+3.3V
P-ON+3.3V
P-ON+5V
EV+11V
EV+11V
GND
1 2 3 4 5 6 7 8 9
10
GND GND
GND
GND GND
GND
PWRCON
FP-CLK
FP-DIN
FP-STB
11 12 13 14 15 16 17 18 19 20
REMOTE-DVD
FP-DOUT
21 22
DVD-POWER
23
DVD-PLAY
DVD-OPEN/CLOSE
24 25
OUTPUT-SELECT
DVD-STOP
26 27
CN401
CN601
PICK UP UNIT
CN201
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20
TS(+) TS(-) FS(-) CD-LD FS(+) GND(DVD-PD) GND(CD-PD) PD-MONI DVD-LD VREF E GND B P-ON+5V CD/DVD D A C F GND(LD)
DETECTOR
FSTS
7 9
11
2 3 6 5 4
TO WIRING DIAGRAM <VCR SECTION>
4 SP(-) 3 SP(+) 6 GND 5 TRAY-IN 8 SL(+) 7 SL(-)
8 9
10
11 12 13 14 15 16 17 18 19
VIDEO-Y(I/P)
GND
VIDEO-C
GND GND
DVD-A(L)
DVD-A(R)-MUTE
DVD-A(R)
DVD-A-MUTE
1 2 3 4 5 6 7
VIDEO-Y(I)
I/P-SW(NU)
ASPECT(NU)
VIDEO-Cr
GND
GND
VIDEO-Cb
AUDIO+5V
AUDIO+5V
SPDIF
