1-16-2 H9622PIN
Notes:
Abbreviation for Active Level:
PWM -----Pulse Wide Modulation
A/D--------Analog - Digital Converter
47 IN D-PFG
Drum PG/FG Input
Signal
PULSE
48 - N.U. Not Used -
49 IN C-FG
Capstan Motor
Rotation Detection
Pulse
PULSE
50 - AFG GND -
51 OUT VRO
Servo Standard
Voltage Output
-
52 IN VRI
Servo Standard
Voltage Input
-
53 - AVss AVSS -
54 IN CTLA CTL Amp. AC GND -
55 - AVDD AVDD -
56
IN/
OUT
CTL (+)
Playback/Record
Control Signal (+)
-
57
IN/
OUT
CTL (-)
Playback/Record
Control Signal (-)
-
58 OUT CTL
Amp. Output
Control Signal for
Test Point
-
59 IN
HiFi/NOR-
IN
Audio Mode Input
HiFi=”L”/
Normal=”H”
A/D
60
IN
DVD-POW-
MONITOR
DVD Power Monitor
Signal (P-off="L", P-
on="H")
H/L
61 IN ST/SAP-IN
Tuner Stereo/Sap
Detector Signal
Input
A/D
62 IN END-S
Tape End Position
Detect Signal
A/D
63 IN AFC
Automatic
Frequency Control
Signal
A/D
64 IN V-ENV
Video Envelope
Comparator Signal
A/D
65 IN PG-DELAY
Video Head
Switching Pulse
Signal Adjusted
Voltage
A/D
66 IN KEY-2
A/D Key Data Signal
2
A/D
67 IN KEY-1
A/D Key Data Signal
1
A/D
68 IN LD-SW
Deck Mode Position
Detector Signal
A/D
69 IN ST-S
Tape Start Position
Detector Signal
A/D
70 OUT DVD-L-IND
VCR Mode LED
Signal Output
H/L
71 OUT DVD-H-IND
DVD Mode LED
Signal Output
H/L
Pin
No.
IN/
OUT
Signal
Name
Function
Active
Level
72 -
N.U. Not Used
-
73 -
N.U. Not Used
-
74 -
N.U. Not Used
-
75 -
N.U. Not Used
-
76 OUT CONV-SW
RF Conv. Output
Channel Switching
Signal 3ch=”Hi-z”,
4ch=”L”
Hi-z/L
77 OUT VCR/TV
RF Conv. ON/OFF
Signal (TV="L"/
VCR="H")
H/L
78 OUT C-ROTA
Color Phase Rotary
Changeover Signal
H/L
79 OUT H-A-SW
Video Head Amp
Switching Pulse
H/L
80 IN H-A-COMP
Head Amp
Comparator Signal
H/L
Pin
No.
IN/
OUT
Signal
Name
Function
Active
Level
