Philips DVP620VR/00 - Page 260

1-15-2 H9723TI
Still/Slow Control
Frame Advance Timing Chart
1) SP Mode
Fig. 1
18 RF-SW
F-AD
(Internal Signal)
C-DRIVE
PB CTL
78 C-F/R
16 H-A-SW
15 C-ROTA
The first rise of RF-SW after a rise in F-AD signal
Acceleration Detection (T1)
AT
"H"
"Z"
"H"
"L" "L"
Stop detection (T2)
ST
Slow Tracking Value
BL
Reversal Limit Value
STILL FRAME ADVANCE STILL
20ms
