TRANSISTORS
ELECTRICAL PARTS LIST
1-18-3
Q304 9965 000 13683 KTC3875Y-RTK
Q305 4822 130 42959 2SA1015Y
Q305 4822 130 11101 2SA1015GR (ALTERNATIVE)
Q307 4822 130 42959 2SA1015Y
Q307 4822 130 11101 2SA1015GR (ALTERNATIVE)
Q308 9965 000 13683 KTC3875Y-RTK
Q401 4822 130 42959 2SA1015Y
Q401 4822 130 11101 2SA1015GR (ALTERNATIVE)
Q402 4822 130 42292 2SC2120Y
Q403 4822 130 10145 KRA103M
Q403 9965 000 05388 BN1F4M-T (ALTERNATIVE)
Q405 9965 000 16623 FMG4A T148
Q405 9965 000 12361 RN1511(TE85R) (ALTERNATIVE)
Q506 9965 000 08630 PHOTO PT204-6B-12
Q506 9965 000 20922 PHOTO MID-32A22F (ALTERNATIVE)
Q515 4822 130 10923 KTC3199(BL)
Q515 4822 130 11692 2SC2785K (ALTERNATIVE)
Q515 4822 130 41319 2SC1815BL (ALTERNATIVE)
Q770 4822 130 10103 KTC3199Y
Q770 4822 130 11647 2SC2785J (ALTERNATIVE)
Q770 9965 000 09882 BN1L4M-T (ALTERNATIVE)
Q771 4822 130 10103 KTC3199Y
Q771 4822 130 11647 2SC2785J (ALTERNATIVE)
Q771 9965 000 09882 BN1L4M-T (ALTERNATIVE)
Q1001! 9965 000 17186
!
FET 2SK3566
Q1003 4822 130 41306 2SC1815GR
Q1004 4822 130 63144 2SA1267(YG)
Q1004 4822 130 11646 2SA1175J (ALTERNATIVE)
Q1008 4822 130 10103 KTC3199Y
Q1008 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1008 9965 000 09882 BN1L4M-T (ALTERNATIVE)
Q1052 4822 130 42292 2SC2120Y
Q1053 4822 130 63144 2SA1267(YG)
Q1053 4822 130 11646 2SA1175J (ALTERNATIVE)
Q1054 4822 130 10103 KTC3199Y
Q1054 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1054 9965 000 09882 BN1L4M-T (ALTERNATIVE)
Q1055 4822 130 42292 2SC2120Y
Q1202 4822 130 10103 KTC3199Y
Q1202 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1202 9965 000 09882 BN1L4M-T (ALTERNATIVE)
Q1204 4822 130 42959 2SA1015Y
Q1204 4822 130 11101 2SA1015GR (ALTERNATIVE)
Q1351 4822 130 10103 KTC3199Y
Q1351 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1351 9965 000 09882 BN1L4M-T (ALTERNATIVE)
Q1352 4822 130 10103 KTC3199Y
Q1352 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1352 9965 000 09882 BN1L4M-T (ALTERNATIVE)
POWER SW CBA
D651 9965 000 08621 LED(RED) 204HD/E
SW651 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW651 4822 276 13954 KSM0614B (ALTERNATIVE)
DVD OPEN/CLOSE CBA
SW2020 4822 276 13954 KSM0614B (ALTERNATIVE)
SW2020 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SENSOR CBA
Q503 9965 000 08630 PHOTO PT204-6B-12
Q503 9965 000 20922 PHOTO MID-32A22F (ALTERNATIVE)
Q504 9965 000 08630 PHOTO PT204-6B-12
Q504 9965 000 20922 PHOTO MID-32A22F (ALTERNATIVE)
Note: Only the parts mentioned in this list are normal service spare parts.
AFV PCB ASSEMBLY CPD0500/9701
D2 4822 130 30621 1N4148
D2 4822 130 32778 1SS133 (ALTERNATIVE)
IC1 9965 000 14760 MSP3417G-QG-B8-V3
L1 4822 157 10889 10UH
L3 4822 157 11318 18UH 10%
L4 4822 157 10889 10UH
X1 9965 000 12200 X’TAL 18.432MHZ
Note: Only the parts mentioned in this list are normal service spare parts.
