V-ENV Video Envelope Comparator Signal
V-IN Video Signal Input
V-IN-F Video Signal Input (Front)
V-OUT Video Signal Output
Vcc Vcc
VCR-LED “VCR” LED Signal Output
VDD Power Supply
VEE Pull Down Level
VIDEO-B Component Video (blue) Signal
VIDEO-C
Composite Video (chrominance)
Signal
VIDEO-G Component Video (green) Signal
VIDEO-R Component Video (red) Signal
VIDEO-Y
Composite Video (Luminance)
Signal
Vss Vss(GND)
XCin Sub Clock
XCOUT Sub Clock
Xin Main Clock Input
Xout Main Clock Input
Signal Name Function
