Philips DVP620VR/00 - Page 77

PSV CBA UNIT
PSV CBA UNIT consists of POWER SUPPLY CBA, JUNCTION CBA and JACK
CBA
POWER SUPPLY CBA
MISCELLANEOUS
AC1001 9965 000 20940
!
AC CORD /00/02
AC1001 9965 000 20990
!
AC CORD /05
F1001 4822 070 31602
!
FUSE21801.6(1.6A) (ALTERNATIVE)
F1001 9965 000 19671
!
FUSE 50T016H 1.6A/250V
IC1001 9965 000 19672
!
PHOTOCOUPLER EL817A
IC1001 9965 000 24000
!
PS2561A-1(Q) (ALTERNATIVE)
R1001 9965 000 20944 GL GLAZE RES. 1/2W J 5.6MOHM
R1001 9965 000 24001 S1/2W J 5.6M OHM (ALTERNATIVE)
R1004 4822 053 11823 82K 5% 2W
R1004 4822 053 11823 82K 5% 2W (ALTERNATIVE)
R1004 9965 000 24002 METAL OXIDE 2W J 82K (ALTERNATIVE)
R1011 9965 000 24003 METAL OXIDE 1W J 1.3 OHM
R1043 9965 000 09861 METAL OXIDE FILM RES. 1W J 150K
R1043 4822 117 12744 2.7R 5% 1W (ALTERNATIVE)
R1043 9965 000 24004 METAL OXIDE 1W J 2.7 OHM
SA1001 9965 000 20946 SURGE ABSORBER PVR-10D471KB
SA1001 9965 000 08602 ABSORB CNR-10D471K (ALTERNATIVE)
T0011 9965 000 24005
!
SW TRANSFORMER CGS-SW0001F
CAPACITORS
C013 9965 000 14852 ELCAP 10UF/50V M
C013 9965 000 19661 ELCAP. 10UF/50V M (ALTERNATIVE)
C014 9965 000 14853 ELCAP 470UF/16V M
C014 9965 000 19567 ELCAP. 470UF/16V M (ALTERNATIVE)
C015 9965 000 15246 ELCAP 100UF/16V M
C017 9965 000 14857 ELCAP 1000UF/16V M
C018 4822 124 42027 470UF20% 6,3V
C018 9965 000 19558 ELCAP. 470UF/6.3V M (ALTERNATIVE)
C020 9965 000 14855 ELCAP 22UF/50V M
C020 9965 000 19549 ELCAP. 22UF/50V M (ALTERNATIVE)
C022 9965 000 19663 ELCAP. 470UF/35V M
C022 9965 000 19655 ELCAP. 470UF/35V M (ALTERNATIVE)
C1001 9965 000 14854
!
MET FILM 0.068UF/275V K
C1001 9965 000 06521
!
MET FILM 0.068UF/250 (ALTERNATIVE)
C1001 9965 000 23998
!
MET FILM 0.068UF/250V (ALTERNATIVE)
C1001 9965 000 09743
!
MET FILM 0.068UF/250 (ALTERNATIVE)
C1004 9965 000 13677 ELCAP 100UF/400V M
C1005 4822 126 14141 56PF 1KV (ALTERNATIVE)
C1005 9965 000 06567 CERAMIC CAP. SL J 56PF/1KV
C1006 9965 000 23354
!
SAFETY CAP. 2200PF/250V
C1007 9965 000 19664 ELCAP. 1000UF/6.3V M
C1018 4822 124 41584 100UF 20% 10V
C1018 9965 000 19666 ELCAP. 100UF/10V M (ALTERNATIVE)
C1032 9965 000 19554 ELCAP. 10UF/16V M
C1035 4822 124 42027 470UF20% 6,3V
C1035 9965 000 19558 ELCAP. 470UF/6.3V M (ALTERNATIVE)
C1106 9965 000 19667 ELCAP. 100UF/35V M
C1106 9965 000 19656 ELCAP. 100UF/35V M (ALTERNATIVE)
C1107 9965 000 19660 ELCAP. 220UF/6.3V M
C2014 4822 126 14142 0.01UF 500V
C2015 4822 124 42027 470UF20% 6,3V
C2015 9965 000 19558 ELCAP. 470UF/6.3V M (ALTERNATIVE)
DIODES
D013 4822 130 11654 BA158
D014 9965 000 19668 SCHOTTKY BARRIER DIODE SB390
D015 9965 000 08649 DZ-5.6BSCT265
D015 4822 130 10926 UZ5.6BSC (ALTERNATIVE)
D016 4822 130 32715 SB340
D017 9965 000 23356 DZ-18BSBT265
D017 9965 000 13882 MTZJT-7718B (ALTERNATIVE)
D018 4822 130 11654 BA158
D019 9965 000 19669 RECTIFIER DIODE FR203
D1001 4822 130 31933 1N5061
D1001 9965 000 23978 1N4005 (ALTERNATIVE)
D1002 4822 130 31933 1N5061
D1002 9965 000 23978 1N4005 (ALTERNATIVE)
D1003 4822 130 31933 1N5061
D1003 9965 000 23978 1N4005 (ALTERNATIVE)
D1004 4822 130 31933 1N5061
D1004 9965 000 23978 1N4005 (ALTERNATIVE)
D1006 4822 130 30621 1N4148
D1006 4822 130 32778 1SS133 (ALTERNATIVE)
D1008 5322 130 81917 SB140
D1011 5322 130 34979 BYV96E
D1011 9965 000 23999 BA159 (ALTERNATIVE)
D1011 4822 130 81244 ERA22-10 (ALTERNATIVE)
D1012 4822 130 30621 1N4148
D1012 4822 130 32778 1SS133 (ALTERNATIVE)
D1016 9965 000 14882 RECTIFIER DIODE FR101
D1017 9965 000 23356 DZ-18BSBT265
D1017 9965 000 13882 MTZJT-7718B (ALTERNATIVE)
D1018 4822 130 30621 1N4148
D1018 4822 130 32778 1SS133 (ALTERNATIVE)
D1019 9965 000 14881 DZ-6.8BSBT265
D1019 9965 000 23556 MTZJT-776.8B (ALTERNATIVE)
D1022 4822 130 30621 1N4148
D1022 4822 130 32778 1SS133 (ALTERNATIVE)
D1024 4822 130 30621 1N4148
D1024 4822 130 32778 1SS133 (ALTERNATIVE)
D1025 4822 130 30621 1N4148
D1025 4822 130 32778 1SS133 (ALTERNATIVE)
D1030 5322 130 81917 SB140
COILS & FILTERS
L010 9965 000 05627 CHOKE COIL 47UH-K
L010 9965 000 05702 CHOKE COIL 47UH-K (ALTERNATIVE)
L010 9965 000 23990 CHOKE COIL 47UH-K (ALTERNATIVE)
L013 9965 000 05627 CHOKE COIL 47UH-K
ELECTRICAL PARTS LIST
1-18-6
