TECHNICAL DATA
Subject to modification without notice.
General
Power consumption (FR 735, MX 735).........................Å 150 W
Power consumption (FR 755)........................................Å 195 W
Standby power consumption............................................< 2 W
Dimensions, w ´ h ´ d ............................435 ´ 135 ´ 350 mm
Weight (FR 735, MX 735) .................................................8.6 kg
Weight (FR 755) ................................................................9.4 kg
Amplifier part (0.7 % THD, 6 ½, 1 kHz)
Output power, stereo mode (FR 735, MX 735) (DIN)...2 ´ 50 W
Output power, surround mode (FR 735, MX 735)
Front ......................................................................2 ´ 50 W
Center ..........................................................................50 W
Surround ......................................................................50 W
Output power, stereo mode (FR 755) (DIN)...............2 ´ 100 W
Output power, surround mode (FR 755)
Front ....................................................................2 ´ 100 W
Center ........................................................................100 W
Surround................................................................2 ´ 50 W
Bass ................................................................±10 dB at 100 Hz
Treble ..............................................................±10 dB at 10 kHz
Loudness....+6 dB at 100 Hz (-30 dB); +3 dB at 10 kHz (-30 dB)
Total harmonic distortion.........................0.05 % at 1 kHz, 1 W
Frequency response ..................................20–20,000 Hz, ±3 dB
S/N ratio ........................................................................³ 82 dB
Stereo separation (1 kHz) ..............................................³ 45 dB
Crosstalk (1 kHz) ...........................................................² -65 dB
Inputs
Linear inputs ...................................................250 mV at 47 k½
6 CH (FR 755 only) ..........................................250 mV at 47 k½
Front AV (FR 755 only) ....................................250 mV at 22 k½
Outputs
Power supply AC outlet (switched).............totally max. 100 W
Linear outputs...................................................250 mV at 1 k½
Subwoofer pre-out (FR 755 only)..........................0.8 V at 1 k½
Surround pre-out (FR 735, MX 735 only)..............0.8 V at 1 k½
Center pre-out.......................................................0.8 V at 1 k½
Headphones..................................8–600 ½ (3 V e.m.f., 120 ½)
Speakers ...........................................................................³ 6 ½
Surround speakers (FR 735 only)......................................³ 3 ½
Tuner part
Wave range
FM..............................................................87.5–108.0 MHz
MW...............................................................531–1,602 kHz
LW....................................................................153–279 kHz
Sensitivity
Stereo FM ..................................................................41 dBf
Mono FM....................................................................15 dBf
Total harmonic distortion
Stereo FM ...................................................................0.3 %
Mono FM...................................................................0.85 %
Frequency response ...................................63–12,500 Hz ±1 dB
S/N ratio
Stereo FM....................................................................55 dB
Mono FM.....................................................................60 dB
Channel separation.............................................35 dB at 1 kHz
Subject to modification without notice.
Front speakers
Impedance............................................................................6 W
Frequency range ...................................................40–20,000 Hz
Power handling capacity....................................................50 W
Power handling capacity – peak .....................................100 W
Sensitivity..........................................................................89 dB
Drivers ....................................1 ´ 5
1
⁄4" woofers, 1 ´ 2" tweeter
Passive radiator .................................................1 ´ 6
1
⁄2" woofer
Crossover frequencies ..................................................4,000 Hz
Dimensions, h ´ w ´ d ............................421 ´ 219 ´ 191 mm
Weight..................................................................approx. 2.5 kg
Rear speakers
Impedance............................................................................3 W
Frequency range .................................................100–20,000 Hz
Power handling capacity....................................................25 W
Power handling capacity – peak .......................................50 W
Sensitivity..........................................................................89 dB
Drivers..............................................................1 ´ 4" full range
Passive radiator .................................................1 ´ 6
1
⁄2" woofer
Crossover frequencies ..................................................4,500 Hz
Dimensions, h ´ w ´ d ..............................179 ´ 181 ´ 92 mm
Weight.........................................................approx. 0.7 kg each
Center speaker
Impedance............................................................................6 W
Frequency range ...................................................75–20,000 Hz
Power handling capacity....................................................50 W
Power handling capacity – peak .....................................100 W
Sensitivity..........................................................................89 dB
Drivers ......................................2 ´ 4" woofers, 1 ´ 2" tweeter
Crossover frequencies ..................................................4,500 Hz
Dimensions, h ´ w ´ d ............................131 ´ 435 ´ 122 mm
Weight..................................................................approx. 1.6 kg
