Philips FW-C390 - LOCATION OF PC BOARDS; VERSION VARIATIONS

1-2
LOCATION OF PC BOARDS
/21 /21M /22 /30 /33 /34
Karaoke x x x
News x x
RDS x x
Rotary Encoder (volume control) x x x x x x
Jog Shuttle x x x x x x
Voltage Selector x x
Aux Input x x x x x x
Digital Output
Headphone Socket x x x x x x
Line Output
Matrix Surround Loudspeakers
Standby - FTD Clock Display x x
ECO Standby - Dark x x
ECO6 Tuner board - System Non-Cenelec x x x x x
ECO6 Tuner board - System Cenelec x
ETF7 Tape Module: Non-Autoreverse Ferro x x x x x x
Power 2001Module (30-70W Version) x x x x x x
VERSION VARIATIONS:
Type /Versions: FW-C390
Features &
Board in used:
E
T
F
7
B
O
A
R
D
MAINS
BOARD
POWER BOARD
MAINS SOCKET
BOARD
T
U
N
E
R
B
O
A
R
D
CD KEY BOARD
FRONT
BOARD
KARAOK
E
BOA
RD
AF9
BOARD
HEADPHONE
BOARD
C
D
B
O
A
R
D
