TABLE 8
ADVANCED OSD MODE CONFIGURATION
Mode Menu
Menu Level 1 Menu Level 2 Menu Level 3 Factory Reset
Brightness ADJ Scale Y (FD = 100)
Contrast ADJ Scale Y(FD=50)
Image Control Auto Adjustment Show “Adjusting… ” message Y (no FD)
Horizontal Position ADJ Scale Y (no FD)
Vertical Position ADJ Scale Y (no FD)
Clock ADJ Scale Y (no FD)
Clock Phase ADJ Scale Y (no FD)
Cancel
Save and Return
Color 9300 K
6500 K-sRGB Y (FD = 6500 K-
sRGB )
Custom Color R/G/B Color ADJ Y(FD =100)
Cancel
Save and Return
Language Deutsch
English N (FD=English)
Español
Français
Italiano
Nederlands
Cancel
Save and Return
Management Power Saver On / Off Selection N (FD=ON)
Power On Recall On / Off Selection N (FD=ON)
Mode Display On / Off Selection N (FD=OFF)
Sleep Timer Timer Set Menu N (FD=0;OFF)
Cancel
Save and Return
OSD Control Horizontal OSD Position ADJ Scale N (FD=50)
Vertical OSD Position ADJ Scale N (FD=50)
OSD Timeout ADJ Scale N (FD=30)
Cancel
Save and Return
Factory Reset Yes
No
Exit
5. FOS characteristics
5.1 Test conditions
This specification is defined under the following conditions.
- Input mode: 1024 x 768/60Hz mode (48.3 KHz)
- Warm-up: more than 30 minutes.
- Ambient light: 400 -- 600 lux.
- Ambient temperature: 25 ± 5 °C.
5.2 Check of W HITE-D
Use Minolta CA-110 for color coordinates and luminance check.
Apply a white pattern (pattern 1),
Set brightness = 100%, and contrast = 50%.
Adjust the R, G, B gain, at the screen center area, to meet specification
(1931 CIE chromaticity (X, Y) coordinates).
9300°K 6500°K-sRGB
x (center) 0.283 ± 0.020 0.313 ± 0.020
y (center) 0.297 ± 0.020 0.329 ± 0.020
