Philips MC77 - Location of Printed Circuit Boards

2-2
MAINS BOARD
SOCKET
BOARD
TUNER BOARD
ETF 8
BOARD
DISPLAY BOARD
COMBI BOARD
STANDBY
(POWER)
BOARD
CDC KEY
BOARD
KEY CONTROL
(KEYB.1)
BOARD
JOG
(VOLUME)
BOARD
HEADPHONE
BOARD
LIGHTWASH BOARD
CD MAIN BOARD
3DTC
LOADER
MECHANIC
BOARD
Location of Printed Circuit Boards
Attention:
Lightwash, CDC-key board, standby board and headphone board are part of the Front Control Board.
For details see chapter 8
