Pin Name Pin No. Type Description
Host Interface Pins
XHCS1J 94 I This pin is used to select the command block task file registers.
XHCS3J 93 I This pin is used to select the control block task file registers.
XHIORJ 103 I Asserted by the host during a host I/O read operation.
XHIOWJ 104 I Asserted by the host during a host I/O write operation.
XHDRQ 105 O 1. DMA request. This pin is configured as the DMA request signal, and is
used during DMA transfer between the host and the controller. This pin is
tri-stated when DMA transfers are not enabled.
2. MPEG acknowledge. This pin is used as the ACKJ signal when MPEG
interface mode is selected.
XHDACKJ 101 I 1. DMA acknowledge. This pin is configured as DACKJ, and is used as the
DMA acknowledge signal during DMA data transfers.
2. MPEG request. This pin is used as the REQ signal when MPEG interface
mode is selected.
XHCS16J 99 O 1. 16-bit data select. This signal indicates that a 16-bit data transfer is active
on the host data bus. This pin is open-drain tri-state output.
2. MPEG clock. This pin is used as the CLOCK signal when MPEG interface
mode is selected.
XHRSTJ 50 I Host Reset. The reset of ATA bus
XHINT 100 O 1. Host interrupt request. This tri-state pin is the host interrupt request, and
is asserted to indicate to the host that the controller needs attention.
2. MPEG begin. This pin is used as the BEGIN signal when MPEG interface
mode is selected.
XHPDIAGJ 97 I/O This pin is used as the Passed Diagnostics signal, and may be an input or an
open-drain output.
XHDASPJ 92 I/O This pin is used as the Drive Active/ Slave Present signal, and is an input or an
open-drain output. This pin is used for Master/Slave drive communication
and/or for driving an LED.
XHIORDY 102 O 1. I/O channel ready. This signal is driven low to extend host transfer cycles
when the controller is not ready to respond. This pin will be tri-stated when a
read or write is not in progress.
2. MPEG error. This pin is used as the ERROR signal when MPEG interface
mode is selected.
XHA[2:0] 95, 98, 96 I Host address lines. The host address lines A[2:0] are used to access the
various host control, status, and data registers.
XHD[15:0] 106, 108,
111, 113,
116, 118,
120, 122,
123, 121,
119, 117,
114, 112,
109, 107
I/O 1. Host data bus. This bus is used to transfer data and status between the
host and the controller.
2. MPEG data bus 7-0. The HD[7:0] are used as the DATA[7:0] when MPEG
interface mode is selected.
3. VCD I/F. Bit3-0 are used as VCD I/F signal when VCD function is enabled.
The relationship of bit3-0 and VCD I/F is as follow.
HD0
CD-DATA
HD1
CD-LRCK
HD2
CD-BCK
HD3
CD-C2PO
Pin Name Pin No. Type Description
RAM Interface Pins
XRSDCLK 143 O This signal is the clock output for SDRAM.
XROEJ 147 O This signal is used as the memory output enable for external DRAM buffers.
After RSTJ is asserted, this signal will be low.
XRWEJ 142 O This signal is asserted low when a buffer memory write operation is active.
XRRASJ 144 O This signal is used as Row address output to external DRAM buffer. After
RSTJ is asserted, this signal will be high.
XRCASJ 145 O This signal is used as column address output to external DRAM. After RSTJ is
asserted, this signal will be high.
XRA[11:0] 151, 152,
148, 149,
153, 155,
156, 157,
161, 160,
159, 158
O 1. RAM address lines. These are bits 11-0 for addressing the buffer memory.
2. Hardware setting. The bits 6-0 are used as hardware setting for some
functions.
RA[9] : FLASH size is 64K/128K
1 : FLASH size is 64K.
0 : FLASH size is 128K.
RA[8] : External CPU is 8032/H8
1 : 8032
0 : H8
RA[7] : Microcontroller programmable I/O port 1 pin control
1 : By internal microcontroller.
0 : By registers to decide input/output.
RA[6] : System testpin output.
1 : Normal operation.
0 : System test pin output.
RA[5] : For testing purpose, don’t need to set
RA[4] : IDE master/slave.
1 : Slave.
0 : Master.
RA[3] : For testing purpose, don’t need to set
RA[2] : For testing purpose, don’t need to set
RA[1-0] : MCU Mode selection.
11 : Normal Mode (internal uP,internal address latch).
10 : Outside uP Mode (ICE Mode).
01 : Test mode for internal uP testing.
00 : Internal uP mode with external address latch.
XRD[15:0] 124, 126,
128, 131,
133, 135,
137, 140,
141, 139,
136, 134,
132, 129,
127, 125
I/O These signals are the 8-bit parallel data lines to/from the buffer memory.
M5705 Pins Descriptions
