4137 4822 051 30008 0R Jumper 0603
4138 4822 051 30008 0R Jumper 0603
4139 4822 051 30008 0R Jumper 0603
4140 4822 051 30008 0R Jumper 0603
4141 4822 051 30008 0R Jumper 0603
4142 4822 051 30008 0R Jumper 0603
4143 4822 051 30008 0R Jumper 0603
4144 4822 051 30008 0R Jumper 0603
4145 4822 051 30008 0R Jumper 0603
4146 4822 051 30008 0R Jumper 0603
4147 4822 051 30008 0R Jumper 0603
4148 4822 051 30008 0R Jumper 0603
4149 4822 051 30008 0R Jumper 0603
4150 4822 051 30008 0R Jumper 0603
4152 4822 051 30008 0R Jumper 0603
4153 4822 051 30008 0R Jumper 0603
4154 4822 051 30008 0R Jumper 0603
4155 4822 051 30008 0R Jumper 0603
4156 4822 051 30008 0R Jumper 0603
4157 4822 051 30008 0R Jumper 0603
4158 4822 051 30008 0R Jumper 0603
4159 4822 051 30008 0R Jumper 0603
4160 4822 051 30008 0R Jumper 0603
4161 4822 051 30008 0R Jumper 0603
4163 4822 051 30008 0R Jumper 0603
4164 4822 051 30008 0R Jumper 0603
4165 4822 051 30008 0R Jumper 0603
4166 4822 051 30008 0R Jumper 0603
4168 4822 051 30008 0R Jumper 0603
4169 4822 051 30008 0R Jumper 0603
4170 4822 051 30008 0R Jumper 0603
4171 4822 051 30008 0R Jumper 0603
4172 4822 051 30008 0R Jumper 0603
4173 4822 051 30008 0R Jumper 0603
4174 4822 051 30008 0R Jumper 0603
4175 4822 051 30008 0R Jumper 0603
4176 4822 051 30008 0R Jumper 0603
4177 4822 051 30008 0R Jumper 0603
4178 4822 051 30008 0R Jumper 0603
4179 4822 051 30008 0R Jumper 0603
4180 4822 051 30008 0R Jumper 0603
4181 4822 051 30008 0R Jumper 0603
4182 4822 051 30008 0R Jumper 0603
4183 4822 051 30008 0R Jumper 0603
4184 4822 051 30008 0R Jumper 0603
4185 4822 051 30008 0R Jumper 0603
4186 4822 051 30008 0R Jumper 0603
4187 4822 051 30008 0R Jumper 0603
4188 4822 051 30008 0R Jumper 0603
4189 4822 051 30008 0R Jumper 0603
4190 4822 051 30008 0R Jumper 0603
4191 4822 051 30008 0R Jumper 0603
4192 4822 051 30008 0R Jumper 0603
4193 4822 051 30008 0R Jumper 0603
4194 4822 051 30008 0R Jumper 0603
4195 4822 051 30008 0R Jumper 0603
4196 4822 051 30008 0R Jumper 0603
4197 4822 051 30008 0R Jumper 0603
4198 4822 051 30008 0R Jumper 0603
4199 4822 051 30008 0R Jumper 0603
4200 4822 051 30008 0R Jumper 0603
4201 4822 051 30008 0R Jumper 0603
4202 4822 051 30008 0R Jumper 0603
4203 4822 051 30008 0R Jumper 0603
4204 4822 051 30008 0R Jumper 0603
4205 4822 051 30008 0R Jumper 0603
4206 4822 051 30008 0R Jumper 0603
4207 4822 051 30008 0R Jumper 0603
4208 4822 051 30008 0R Jumper 0603
4209 4822 051 30008 0R Jumper 0603
4210 4822 051 30008 0R Jumper 0603
4211 4822 051 30008 0R Jumper 0603
4212 4822 051 30008 0R Jumper 0603
4213 4822 051 30008 0R Jumper 0603
4214 4822 051 30008 0R Jumper 0603
4215 4822 051 30008 0R Jumper 0603
4216 4822 051 30008 0R Jumper 0603
4217 4822 051 30008 0R Jumper 0603
4218 4822 051 30008 0R Jumper 0603
4219 4822 051 30008 0R Jumper 0603
4220 4822 051 30008 0R Jumper 0603
4221 4822 051 30008 0R Jumper 0603
4222 4822 051 30008 0R Jumper 0603
4223 4822 051 30008 0R Jumper 0603
4224 4822 051 30008 0R Jumper 0603
4225 4822 051 30008 0R Jumper 0603
4226 4822 051 30008 0R Jumper 0603
4227 4822 051 30008 0R Jumper 0603
4228 4822 051 30008 0R Jumper 0603
4229 4822 051 30008 0R Jumper 0603
4230 4822 051 30008 0R Jumper 0603
4231 4822 051 30008 0R Jumper 0603
4232 4822 051 30008 0R Jumper 0603
4234 4822 051 30008 0R Jumper 0603
4235 4822 051 30008 0R Jumper 0603
4236 4822 051 30008 0R Jumper 0603
4237 4822 051 30008 0R Jumper 0603
4238 4822 051 30008 0R Jumper 0603
4239 4822 051 30008 0R Jumper 0603
4240 4822 051 30008 0R Jumper 0603
4241 4822 051 30008 0R Jumper 0603
4242 4822 051 30008 0R Jumper 0603
4243 4822 051 30008 0R Jumper 0603
4244 4822 051 30008 0R Jumper 0603
4245 4822 051 30008 0R Jumper 0603
4246 4822 051 30008 0R Jumper 0603
4247 4822 051 30008 0R Jumper 0603
4249 4822 051 30008 0R Jumper 0603
4250 4822 051 30008 0R Jumper 0603
4251 4822 051 30008 0R Jumper 0603
4254 4822 051 30008 0R Jumper 0603
4255 4822 051 30008 0R Jumper 0603
4256 4822 051 30008 0R Jumper 0603
4257 4822 051 30008 0R Jumper 0603
4301 4822 051 30008 0R Jumper 0603
4302 4822 051 30008 0R Jumper 0603
4303 4822 051 30008 0R Jumper 0603
4304 4822 051 30008 0R Jumper 0603
4305 4822 051 30008 0R Jumper 0603
4306 4822 051 30008 0R Jumper 0603
4307 4822 051 30008 0R Jumper 0603
4308 4822 051 30008 0R Jumper 0603
4309 4822 051 30008 0R Jumper 0603
4310 4822 051 30008 0R Jumper 0603
4311 4822 051 30008 0R Jumper 0603
4312 4822 051 30008 0R Jumper 0603
4313 4822 051 30008 0R Jumper 0603
4314 4822 051 30008 0R Jumper 0603
4315 4822 051 30008 0R Jumper 0603
4316 4822 051 30008 0R Jumper 0603
4317 4822 051 30008 0R Jumper 0603
4318 4822 051 30008 0R Jumper 0603
4319 4822 051 30008 0R Jumper 0603
4320 4822 051 30008 0R Jumper 0603
4321 4822 051 30008 0R Jumper 0603
4322 4822 051 30008 0R Jumper 0603
4323 4822 051 30008 0R Jumper 0603
4324 4822 051 30008 0R Jumper 0603
4325 4822 051 30008 0R Jumper 0603
4326 4822 051 30008 0R Jumper 0603
4327 4822 051 30008 0R Jumper 0603
4328 4822 051 30008 0R Jumper 0603
4329 4822 051 30008 0R Jumper 0603
4330 4822 051 30008 0R Jumper 0603
4332 4822 051 30008 0R Jumper 0603
4334 4822 051 30008 0R Jumper 0603
4337 4822 051 30008 0R Jumper 0603
4338 4822 051 30008 0R Jumper 0603
4339 4822 051 30008 0R Jumper 0603
4342 4822 051 30008 0R Jumper 0603
4343 4822 051 30008 0R Jumper 0603
4400 4822 051 30008 0R Jumper 0603
4500 4822 051 30008 0R Jumper 0603
4501 4822 051 30008 0R Jumper 0603
4600 4822 051 30008 0R Jumper 0603
4601 4822 051 30008 0R Jumper 0603
4602 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5100 3198 018 52280 Fixed Inductor 2,2uH 10%
5101 3139 110 53431 VU Meter FG-PH16CATS00 Black
5102 5322 242 73686 Ceram Resonator 12MHz
5103 4822 242 70938 X’tal 32,768kHz
5104 3198 018 52280 Fixed Inductor 2,2uH 10%
5105 4822 242 11033 X'tal Resonator 4,332MHz
RDS
5600 2422 549 44607 Fixed Ind 100MHz 600R
5603 4822 157 10586 Coil 2,2uH 10%
kara
5604 2422 549 44607 Fixed Ind 100MHz 600R
5605 2422 549 44607 Fixed Ind 100MHz 600R
5606 2422 549 44607 Fixed Ind 100MHz 600R
DIODES
6104 9322 190 55676 LTL-816TDK3
6105 4822 130 80622 BAT54
6106 4822 130 31878 1N4003G
6108 4822 130 11397 BAS316
6113 4822 130 31878 1N4003G
6118 4822 130 80622 BAT54
6119 4822 130 31878 1N4003G
6300 9322 190 55676 LTL-816TDK3
6302 9322 190 55676 LTL-816TDK3
6305 9322 190 55676 LTL-816TDK3
6307 9322 190 55676 LTL-816TDK3
6500 9322 179 76676 LTL-816EELC
6501 9322 183 96676 LTL-816GE
TRANSISTORS & INTEGRATED CIRCUITS
7100 3139 110 53501 TMP88CU74F mark "5500S53501"
7101 5322 130 60159 BC847B
7102 9352 686 05118 SAA6581T
RDS
7103 9322 145 26668 M24C02-WMN6
7104 5322 130 60159 BC847B
7105 5322 130 60159 BC847B
7106 5322 130 60159 BC847B
7107 5322 130 60159 BC847B
7300 4822 209 15449 74HC4094D
7301 5322 130 60159 BC847B
7303 5322 130 60159 BC847B
7306 5322 130 60159 BC847B
7308 5322 130 60159 BC847B
7500 5322 130 60159 BC847B
7501 9322 185 95667 IR RECEIVER TSOP4836
7504 5322 130 60159 BC847B
7600 5322 130 60159 BC847B
kara
7601 5322 130 60159 BC847B kara
Note: Only the parts mentioned in this list are normal service
spare parts.
6-17
ELECTRICAL PARTS LIST - FRONT BOARDS
6-17
ELECTRICAL PARTS LIST - FRONT BOARDS
RESISTORS
