Bill of Materials
Bill of materials of the PDIUSBD12 evaluation board
Item Quantity Reference Part
1 2 C2,C1 4.7 TANT
2 8 C3,C8,C9,C10,C11,C12,C14,C16 0.1
3 1 C5 47P
4 1 C6 22P
5 1 C7 10 TANT
6 1 C13 470P, Ceramic
7 1 C15 1000P
8 1 D1 GREEN
9 4 D2,D3,D4,D5 RED
10 1 J1 UP_CONN
11 1 J2 DB25
12 1 J3 CON20A
13 2 L1,L2 Ferrite Bead
14 1 OSC1 Crystal Oscillator
15 5 R1,R12,R13,R14,R15 470
16 2 R2,R3 22 1%
17 2 R4,R5 4.7K
18 4 R7,R8,R9,R10 10K
19 1 R11 1K
20 1 R16 1M
21 4 S1,S2,S3,S4 SW PUSHBUTTON
22 1 S5 BUS POWERED
23 1 U1 PDIUSBD12
24 1 U2 74LS245
25 1 U3 74HCT244
26 1 U4 74LS05
27 1 U5 16L8
28 1 U6 74HCT273
29 1 Y1 6MHz
Bill of materials of the PDIUSBD12 ISA bridging board
Item Quantity Reference Part
1 3 C1,C4,C5 0.1
2 2 C2,C3 4.7u
3 6 JP1,JP2,JP3,JP4,JP5,JP6 JUMPER
4 1 J1 CON AT62
5 1 J2 DB25
6 1 RP1 20K
7 1 R1 10K
8 1 S1 SW DIP-8
9 1 U1 74HCT688
