5.8.11 Upgrade VGA EDID NVM
To upgrade the VGA EDID NVM, pin 7 of the EDID NVM [2] has
to be short circuited to ground. See ComPair for further
instructions.
Figure 5-10 VGA EDID NVM
1
SDM
2
EDID
