Philips Q548.1E - Mechanical Instructions

Mechanical Instructions
EN 9Q548.1E LA 4.
2009-Apr-03
4. Mechanical Instructions
Index of this chapter:
4.1
Cable Dressing
4.2 Service Positions
4.3 Assy/Panel Removal
4.4 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
4.1 Cable Dressing
Figure 4-1 Cable dressing 32PFL7404H/12
Figure 4-2 Cable dressing 42PFL7404H/12
18560_104_090401.eps
090402
18560_102_090401.eps
090402
