7.1.3 SSB Cell Layout
Figure 7-3 Dali SSB layout cells (top view)
18850_208_100204.eps
100222
AUDIO CLASS - D
DC/DC
TUNER
ANALOG I/O
SERVICE
CONNECTOR
TCON
MT5363H
COMMON INTERFACE
DIGITAL I/O
