Philips TPM5.1E - Block Diagram Smart Choice

EN 48TPM5.1E LA 9.
Block Diagrams
2011-Sep-2
Block Diagram Smart Choice
18840_400_100412.eps
100428
64 MB DDR2 × 2
NAND Flash 16MB
24C64
NVM
SPI
24C02
HDMI EDID
REAR HDMI
TUNER
NOR Flash 512KB
LED LCD Panel
CVBS1
24C02
HDMI EDID
REAR HDMI
SIDE HDMI
ADIN4_SRV,ADIN2_SRV
IF BPF
CVBS1
SIDE AV
VGA
24C02
VGA EDID
OIRI, OPCTRL0
R1,G1,B1
Component
VDAC_OUT1
HP AMP
TPA6132A2
Audio AMP
TPA3113D2
SCART
AR0 AL0
SCART
MP3/JPEG
S/W upgrade/NVM clone
AR0
,
AL0
DRV603
CI card IN
TTL/ LVDS
